TSL 1166 Bluetooth ® Rugged UHF RFID RAIN Reader
The 1166 Bluetooth® Rugged UHF RFID Reader provides high performance mobile UHF RFID reading and writing with all host devices in an ultra-tough form factor.
- SealingIP67*. *Please note; that this IP rating only applies to units with serials numbers ending in -000800 or…
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Specifications
Specifications
- Dimensions
- 178.7 x 107.3 x 173.1 mm (LxWxH).
- Weight
- 865 g / 30.5 oz (including battery).
- User input
- Single stage trigger.
- User feedback
- Speaker, vibration motor, LEDs.
- Charging / power
- Removable, rechargeable 10.8V, 3350mAh, 36.2Wh Lithium Ion battery pack.
- Minimum operating time 1
- Light use 2 : 25 hrs Moderate use 3 : 16.5 hrs Heavy use 4 : 8 hrs
- Light use 2
- 25 hrs
- Moderate use 3
- 16.5 hrs
- Heavy use 4
- 8 hrs
- Enclosure materials
- Polycarbonate and TPU.
- RFID
- TSL ® custom module with embedded Impinj R2000.
- Communication protocols
- TSL ® ASCII 2.0 parameterised command set.
- RAM / storage options
- Embedded 16GB* NAND storage card – store up to 250 million date and time stamped EPCs * For units manufactured in August 2020 onwards. Units sold before this time will have 4GB or 8GB of storage.
- Compatible Host devices (Bluetooth ® )
- Any Bluetooth ® Host 5 supporting the Serial Port Profile (SPP) or Human Interface Device (HID) profile (Android, iOS, Linux, Mac, Windows). Comparison of Bluetooth ® modes for TSL ® UHF Readers.
- Compatible Host devices (USB)
- Any USB host with FTDI VCP driver support (Windows, Linux, Mac, Android).
- Operating temperature
- -10°C to 50°C (14°F to 122°F).
- Charging Temp.
- 5°C to 40°C (41°F to 104°F).
- Storage temperature
- Less than 1 month at at -20 to +60°C (-4°F to 140°F). Less than 3 months at -20°C to +45°C (-4°F to 113°F). Less than 1 year at -20°C to +20°C (-4°F to 68°F).
- Humidity
- 5% to 85% non-condensing.
- Drop Spec
- 1.8 m.
- Tumble specification
- 1500 0.5 metre tumbles at room temperature (3,000 cycles).
- IP / sealing
- IP67*. *Please note; that this IP rating only applies to units with serials numbers ending in -000800 or higher
- Electrostatic Discharge (ESD)
- ± 15kVdc air discharge; ± 8kVdc contact discharge.
- MIL-STD 810F
- Meets and exceeds applicable MIL-STD 810F for drop, tumble and sealing.
- RFID
- EPC Class 1 Gen 2 and EPC C1G2 (TBD).
- Nominal read range 6
- Up to 9 m (29.5 ft).
- Field
- 110-degree forward facing (approx.) measured from front of device.
- Antenna
- Circularly Polarized.
- Frequency Range
- EU: 865-868MHz; US: 902-928MHz.
- Maximum Output Power
- Up to 30 dBm (region dependent) + 4.0 dBiC Antenna
- Optional 2D Barcode Engine
- Optional TSL ® custom 2D Barcode Scan Engine module.
- Sensor Resolution
- 1280 x 960 pixels, rolling shutter
- Field of View
- Horizontal: 44.5°, vertical: 33.5°
- Focal Distance
- From front of engine: 15.24 cm (6 in.)
- Aiming LED
- Green LED
- Illumination
- 1 warm white LED
- Symbologies Supported
- 1D: All major codes 2D: PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX).
- Bluetooth
- Bluetooth ® Version 2.1.
- Bluetooth ® Frequency Range
- 2.4 – 2.4835 GHz.
- Bluetooth ® Profiles
- SPP Profile. HID Profile. Apple iAP.
- Bluetooth ® Power
- Class 2.
- Bluetooth ® Range 7
- 30m.
- Bluetooth ® Pairing
- PIN, Simple Secure Pairing, NFC OOB Pairing.
- External interface
- 8-way sealed connector with gold plated contacts.
- Bundled accessories
- Battery.
- Other accessories available
- Docking Station with power and Mini USB cable. Adapter mounts for a variety of smartphones, handheld terminals and touchscreen devices.
- Regions
- EU (CE), USA (FCC), Canada, New Zealand and more (see page 4 for details)
- FCC ID
- S6J1166
- IC
- 8948A-1166
- EMC
- EN 55032:2015 +A11:2020 EN 55035:2017 +A11:2020 47 CFR Part 15B ICES-003:2020 Issue 7
- RF
- EN 300 328 V2.2.2 EN 302 208 V3.2.0 EN 301 489-1 V2.2.3 EN 301 489-3 V2.1.1 EN 301 489-17 V3.2.4 47 CFR Part 15C 15.247 RSS-247 Issue 1
- RF Exposure
- EN 50566:2013 EN 62209-1:2016 EN 62209-2:2010 EN 62479:2010 47 CFR Part 2.1093 RSS-102 Issue 5
- Electrical Safety
- IEC 62368-1:2018 EN 62368-1:2020 +A11:2020 UL 62368-1:2019 CAN/CSA C22.2 No. 62368-1:19
- Environmental
- 2011/65/EU (RoHS 2) Restriction of the use of certain Hazardous Substances in electrical and electronic equipment 2015/863 (RoHS 3) Amendment to Annex II of 2011/65/EU
- United States of America (USA) Guam Guatemala Northern Mariana Islands
- Canada Ecuador Puerto Rico
- 1166/3166 Docking Station Kit, 65W PSU and Mini USB lead
- 1166-CRD-01-KIT
- Line Cord (UK Plug, 2m)
- IEC-2M-UK
- Line Cord (US Plug, 1.8m)
- IEC-1.8M-US
- Line Cord (EU Plug, 1.8m)
- IEC-1.8M-EU
- Line Cord (AU/NZ Plug, 2m)
- IEC-2M-AU-NZ
