TSL · RFID reader
TSL 3166 Bluetooth® Rugged UHF RFID RAIN Reader
The new 3166 Bluetooth® Rugged UHF RFID RAIN Reader boasts TSL’s latest hardware innovations and performance improvements, in a more efficient reader with a longer battery life.
- ScanningOptional 2D Barcode
- SealingIP67.
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Videos
Specifications
Platform
- RAM / storage options
- Embedded 32GB storage memory – store up to 500 million date and time stamped EPCs
Data capture
- Scan engines / capture options
- Optional 2D Barcode
- RFID
- TSL ® custom module with embedded Impinj E710. EPC Class 1 Gen 2 v2
Power
- Charging / power
- Rechargeable Lithium Ion removeable battery pack (10.8V, 3.35Ah, 36.2Wh). Up to 30 dBm (region dependent)
Connectivity
- Bluetooth
- Bluetooth ® Version 4.2 compliant (v5.1 compatible).
Rugged
- IP / sealing
- IP67.
- Tumble specification
- 1500 0.5 metre tumbles at room temperature (3,000 cycles).
- Operating temperature
- -20°C to 55°C (-4°F to 131°F).
- Storage temperature
- Less than 1 month at at -20 to +60°C (-4°F to 140°F). Less than 3 months at -20°C to +45°C (-4°F to 113°F). Less than 1 year at -20°C to +20°C (-4°F to 68°F).
- Humidity
- 5% to 85% non-condensing.
Size
- Weight
- 865 g / 30.5 oz (including battery).
- Dimensions
- 178 x 105 x 172 mm (LxWxH).
Software & service
- Warranty
- The TSL 3166 reader is warranted against manufacturing defects
