Unitech · Display
Unitech MS926P
MS926P is a 2D pocket scanner with 1-inch OLED display and the USB dongle.
- Operating systemProprietary, Connect to host with Windows, Android and iOS
- Display1" OLED, 128 x 64
- BatteryRechargeable Li-ion battery battery 680 mAh
- SealingIP42
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Specifications
Platform
- Operating system
- Proprietary, Connect to host with Windows, Android and iOS
- RAM / storage options
- RAM 64 Kbytes Flash 2MB
Display
- Display size
- 1" OLED, 128 x 64
Data capture
- Scan range / decode distances
- (DOF PCS=80%) Decode Range | Near | Far EAN-13, 13 mils | 6.0 cm | 29 cm Code 39, 5 mils | 5.5 cm | 16.5 cm PDF417, 6.7 mils | 5.5 cm |13.5 cm Data Matrix, 10 mil | 5.5 cm | 13 cm QR, 15 mil | 4.5 cm |17.5cm
Power
- Battery / runtime
- Rechargeable Li-ion battery battery 680 mAh
Rugged
- IP / sealing
- IP42
- Operating temperature
- 0°C to 50°C
- Storage temperature
- -30°C to 70°C
- Humidity
- 5% to 90% non-condensing
Size
- Weight
- 63g
- Dimensions
- H21.1*W36.9*L95.9mm
