ProDVX · Display
ProDVX TMP-15X
TMP-15X (R24-1001) Art. No: 3015105 15.6" Touch Monitor Display 10-Point PCAP touch Non-glare panel Get Quote Request demo device
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Specifications
Specifications
- Panel type
- TFT LCD IPS
- Resolution
- 1920 x 1080
- Aspect ratio
- 16:9 wide
- Backlight
- Edge-LED backlight
- Brightness
- 400 cd/m2
- Viewing angle
- H170 / V170
- Contrast ratio
- 800 to 1
- Touch Type
- 10 TP Pcap 10ms
- Treatment
- Non-glare
- Convenience
- Landscape,Portrait,Table Mode
- Operation hours
- 24h / 7d
- Monitor
- YES
- Cooling
- Fanless
- Video input
- HDMI
- Video resolution
- 1920 x 1080
- USB Host
- 1 x
- Ports / interfaces
- 12 V DC-IN,HDMI-in 1.4,USB 2.0
- Speakers
- 2 x 2 W
- Audio Jack Output 3.5mm
- YES
- Housing
- ABS+PC (Macrolon)
- Color
- Black
- Weight
- 1200 g
- Dimensions
- 387,3 x 241,2 x 27,2 mm
- Mounting / VESA
- VESA 100
- Charging / power
- 12 V / 2 A (EU, UK, US)
- Power Supply Included?
- Yes
- Power Usage
- 10 Watt
- OSD Language
- no OSD
- Storage temperature
- -10~55 degrees C
- Working Temp
- 0 ~ 40 degrees C
- Storage/Working Humidity
- 0 ~ 95% non-condensing
- MTBF
- 45,000 hours demonstrated
- Standard Warranty
- 3 years
- Certifications
- CE, RoHS, REACH
- Art. No
- 3015105
Send a request
Get a quote for the TMP-15X
Tell us where you are and what you need.
Raptool does NOT sell hardware. We are a pure software company. The devices are sold by our hardware partners around the world. Your request goes straight to a partner in your country, and they send you the quote.
