ProDVX · Panel PC
ProDVX APPC-13XP
Discover the APPC-13XP! This 13 inch Android SOC touch display features Android 9, Power over Ethernet & 10-point PCAP touch.
- Operating systemAndroid 13
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Specifications
Specifications
- Panel type
- TFT LCD IPS
- Resolution
- 1920 x 1080
- Aspect ratio
- 16:9 wide
- Backlight
- Edge-LED backlight
- Brightness
- 300 cd/m2
- Viewing angle
- H170 / V170
- Contrast ratio
- 800 to 1
- Touch Type
- 10 TP Pcap 10ms
- Treatment
- Non-glare
- Convenience
- Landscape,Portrait,Table Mode
- Operation hours
- 24h / 7d
- Processor
- Cortex A55, 2.0 GHz, 4-Core
- Processor
- RK3568 (Quad-core ARM Cortex-A55)
- GPU
- Mali-G52
- Cooling
- Fanless
- RAM / storage options
- 4 GB DDR4 SDRAM
- Video out
- Yes, mini-HDMI out
- Internal storage
- 16 GB eMMC Flash
- External storage
- SD-Card Slot (door)
- Card slot
- SD
- Operating system
- Android 13
- LED Light Bar
- via PoGo
- Ports / interfaces
- 12 V DC-IN,Micro-USB,RJ45,mini-hdmi-out,USB 2.0,GPIO,3.5 mm jack in/out,USB 3.0,3x Pogo pin
- Network LAN RJ45
- 10/100/1000 Mbps LAN
- Wi-Fi / WLAN
- 802.11 a/b/g/n
- Bluetooth
- 5
- Power over Ethernet (PoE)
- IEEE 802.3at (PoE+)
- Integrated NFC
- via PoGo & USB
- Cameras
- via PoGo & USB
- Video support
- 3GP,ASF,AVI,DAT,FLV,MKV,MOV,VOB,WMV,MP4,MPG,RM,TS
- Audio support
- AAC,ASF,MP2,OGG,WAV,WMA
- Photo support
- JPG,JPEG,PNG,BMP,GIF
- Microphone
- YES
- Speakers
- 2 x 2 W
- Audio Jack Output 3.5mm
- YES
- Housing
- ABS+PC (Macrolon)
- Color
- Black
- Weight
- 1050 g
- Dimensions
- 337,1 x 214,5 x 26,2 mm
- Mounting / VESA
- VESA 75
- Charging / power
- 12 V / 2 A
- Power Supply Included?
- No
- Power Usage
- 10 ~ 23 Watt
- Pogo Pins
- YES (bottom/left/right)
- OSD Language
- Multi OSD language
- Clock Battery (for RTC)
- CR1220 Lithium metal, non rechargeable
- Storage temperature
- -10~55 degrees C
- Working Temp
- 0 ~ 40 degrees C
- Storage/Working Humidity
- 10 ~ 90 % non-condensing
- MTBF
- 45,000 hours demonstrated
- Standard Warranty
- 3 years
- Certifications
- UKCA, CE, FCC, RoHS, REACH
- Art. No
- 5013200
