ProDVX ABPC-4220
ABPC-4220 (R24-4224) Art. No: 7099310 Android Box PC Android 13 Power over Ethernet+ Get Quote Request demo device
- Operating systemAndroid 13
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Specifications
Specifications
- Convenience
- Easy installation
- Operation hours
- 24/7
- Processor
- RK3399 (Dual Core Cortex A72 with Quad Core A53)
- GPU
- MALI T860 / 3D Graphic Engine (4K)
- Cooling
- Fanless
- RAM / storage options
- 4GB DRAM
- Video input
- Yes, mini-HDMI in
- Video out
- Yes, HDMI out
- Internal storage
- 16GB eMMC
- External storage
- MicroSD-Card Slot (door)
- Card slot
- MicroSD
- Operating system
- Android 13
- Ports / interfaces
- 3.5 mm (IR and PIR sensor in),Combo Jack,HDMI-out 2.0,RJ45,USB 2.0,USB 3.0,USB-C,mini-HDMI-in 1.4,1x RS232,GPIO
- Network LAN RJ45
- 10/100/1000 Mbps LAN
- Wi-Fi / WLAN
- 802.11 a/b/g/n/ac 2.4&5GHz (external antenna)
- Bluetooth
- 5
- Power over Ethernet (PoE)
- IEEE 802.3at (PoE+)
- Integrated NFC
- via USB
- Cameras
- via USB
- Video support
- 3GP,ASF,AVI,DAT,FLV,MKV,MOV,VOB,WMV,MP4,MPG,RM,TS
- Audio support
- AAC,ASF,MP2,OGG,WAV,WMA
- Photo support
- JPG,JPEG,PNG,BMP,GIF
- Audio Jack Output 3.5mm
- YES
- Housing
- Metal
- Color
- Blue
- Weight
- 470 g
- Dimensions
- 153,3 x 107 x 30,6 mm
- Mounting / VESA
- VESA 75/100 x 120 mm
- Charging / power
- 12V / 2A DC input
- Power Supply Included?
- No
- Power Usage
- 10 ~ 15 Watt
- OSD Language
- Multi OSD language
- Clock Battery (for RTC)
- CR1220 - Lithium‐metal non‐rechargeable coin
- Storage temperature
- -10~55 degrees C
- Working Temp
- 0 ~ 40 degrees C
- Storage/Working Humidity
- 10 ~ 90% non-condensing
- MTBF
- 45,000 hours demonstrated
- Standard Warranty
- 3 years
- Certifications
- FCC, CE & RoHS
- Art. No
- 7099310
