Raptool ApprovedApproved for use with the Raptool Client and all Raptool apps.Elo Touch · POS computer
Elo Touch EloPOS Z10 with Android
Built on Elo’s unified architecture, the EloPOS Z10 delivers a powerful, minimalistic design to help optimize checkout in compact spaces without losing inches on your point‑of‑sale terminal. Complete
- Operating systemAndroid 14 with Google Play Services and EloView content deployment and management; Planned upgrade to…
- Display15.6'' diagonal, Active matrix TFT LCD (LED)
- SealingTouchscreen optically bonded to LCD
Datasheet at Elo Touch Product page at Elo Touch
Runs Raptool apps in the Raptool Client, with access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Overview
Built on Elo’s unified architecture, the EloPOS Z10 delivers a powerful, minimalistic design to help optimize checkout in compact spaces without losing inches on your point‑of‑sale terminal. Complete with a 15.6‑inch Full HD interactive display, I/O hub, contained cable routing, Android 14 OS and optional interactive customer-facing display, the EloPOS Z10 delivers one of the slimmest POS systems to the market.
- Purposefully architected to fit everything you need at the point of sale into a sleek compact design.
- Offer your customers a point of interaction to review transactions, participate in loyalty programs and see the latest promotions with the customer-facing touchscreen display.
- Connectivity for Accessories The EloPOS Z10 offers an I/O hub that extends connectivity from the display to your accessories.
- Conceal Your Cables Keep your counter clean with the fully-integrated cable routing system.
- Single Cable Connection Connect a secondary display with a single USB cable that provides touch, video and power.
Best for: POS Systems for Restaurants · Retail POS Systems · Android Retail POS Systems
Specifications
Technical
- Part Number(s)
- I-Series 5 Slate: E540697; Z10 Stand: E767159
- Enclosure Color
- Dark Gray Metallic
- Touch Technology & Capacity
- PCAP (TouchPro® Projected Capacitive) - 10 Touch
- Processor
- Qualcomm Snapdragon QCS6490
- Memory (RAM)
- 8GB
- Storage
- 64GB
- OS
- Android 14 with Google Play Services and EloView content deployment and management; Planned upgrade to Android 16 and Android 18 available with OS 360 subscription
- Diagonal Size
- 15.6'' diagonal, Active matrix TFT LCD (LED)
- Aspect Ratio
- 16:9
- Active Area
- 13.55" x 7.62" / 344 mm x 194 mm
- Resolution
- 1920 x 1080 @ 60Hz
- Number of Colors
- 8-bit (16.7 million)
- Brightness (typical)
- LCD Panel: 350 nits; TouchPro PCAP: 280 nits
- Response Time-total (typical)
- 20 ms
- Contrast Ratio
- 1000:1
- Viewing Angle
- Horizontal: ±85° or 170° total / Vertical: ±85° or 170° total
- I/O Ports
- DC Input; 4 x USB-A 3.0 (900mA); RJ45 Ethernet LAN (Gigabit)
- Webcam
- 8MP; Max Resolution: 3264x2448 30fps; Auto Focus
- Wireless
- 802.11a/b/g/n/ac/ax + Bluetooth 5.2
- Audio Ports
- 2x built-in Digital Microphones
- Speakers
- 2x 1W
- Power Supply
- AC input voltage: 100-240 VAC; Input frequency: 50-60 Hz
- Power Consumption (Typical)
- On: 8.5W; Off: 0.4W; Sleep: 3W
- Dimensions
- I-Series 5 Slate: 14.6" x 8.7" x 0.52" / 370.2 mm x 221.2 mm x 13.1 mm; Z10 Stand: 6.9" x 4.9" x 5.3" / 175 mm x 200.7 mm x 134.6 mm
- Shipping Box Dimensions
- I-Series 5 Slate: 17.44" x 12.20" x 6.14" / 443 mm x 310 mm x 156 mm; Z10 Stand: 8.19" x 11.8" x 11.2" / 208 mm x 300 mm x 285 mm
- Weight (Unpackaged)
- I-Series 5 Slate: 3.3 lbs / 1.5 kg; Z10 POS Stand: 2.4 lbs / 1.1 kg
- Weight (Packaged)
- I-Series 5 Slate: 7.6 lbs / 3.5 kg; Z10 POS Stand: 4.41 lbs / 2.0 kg
- Operating Temperature
- 0°C to 40°C / 32°F to 104°F
- Storage Temperature
- -20°C to 50°C / -4°F to 122°F
- Humidity
- Operating: 20% to 80%; Storage: 10% to 90%
- Regulatory approvals and declarations
- UL/cUL (US); FCC (US); IC (Canada); CE (Europe); CB (International); VCCI, MIC (Japan); RCM (Australia); BSMI/NCC (Taiwan); KCC (Korea); CCC/SRRC (China); United Kingdom UKCA
- Supported Countries
- Canada, USA, Australia, Japan, New Zealand, Austria, Belgium, Czech Republic, Denmark, France, Germany, United Kingdom, Hungary, Italy, Netherlands, Poland, Portugal, Romania, Spain, Sweden, Switzerland, Turkey
- Real-Time Clock
- lithium coin cell battery
- MTBF
- 50,000 hours demonstrated
- Mounting Options
- VESA 75mm / Z-Hinge
- Warranty
- 2-year
- Extended Service Options
- I-Series 5 Slate; 3 year OS 360 - Elo P/N: E897877; 4 year OS 360 - Elo P/N: E898079; 5 year OS 360 - Elo P/N: E898282; 3 year Warranty Coverage – Elo P/N: E819394; 4 year Warranty Coverage – Elo P/N: E819598; 5 year Warranty Coverage – Elo P/N: E819795; 3 year Warranty Coverage + ADP – Elo P/N: E130329; 4 year Warranty Coverage + ADP – Elo P/N: E130530; 5 year Warranty Coverage + ADP – Elo P/N: E130719; 2 year Warranty Coverage + AUR – Elo P/N: E819985; 3 year Warranty Coverage + AUR – Elo P/N: E820186; 4 year Warranty Coverage + AUR – Elo P/N: E820388; 5 year Warranty Coverage + AUR – Elo P/N: E820582; 2 year Warranty Coverage + AUR + ADP – Elo P/N: E131490; 3 year Warranty Coverage + AUR + ADP – Elo P/N: E131674; 4 year Warranty Coverage + AUR + ADP – Elo P/N: E131859; 5 year Warranty Coverage + AUR + ADP – Elo P/N: E132053; Z10 POS Stand; 3 year warranty coverage - Elo P/N: E375367; 4 year warranty coverage - Elo P/N: E375573; 5 year warranty coverage - Elo P/N: E375771; 2 year warranty coverage + AUR - Elo P/N: E375970; 3 year warranty coverage + AUR - Elo P/N: E376169; 4 year warranty coverage + AUR - Elo P/N: E376362; 5 year warranty coverage + AUR - Elo P/N: E376547
- OS Support
- Bi-monthly Android security updates available with Elo OS 360 package.
- Sealability
- Touchscreen optically bonded to LCD
- What's in the Box
- I-Series 5 Slate; I-Series 5 Slate; IO Hub; North American Power Cable; European Power Cable; 1x Power Brick 65W (E153026); Quick Install Guide; 4 x M4x6 mm Panhead screws in a plastic bag; Z10 POS Stand; Z10 POS Stand; 2x M4 x 5 screws for attaching the head to the stand; 4 x M4x18 screws for attaching an optional 0702L CFD display; 1x Hex 4X108 Allen wrench for adjusting hinge torque; 1x Back Cover for CFD; Quick Install Guide; Please note, the EloPOS Z10 is shipped in two boxes. One for the head and one for the stand.
- Stands, Mounts & Kits
- I/O Hub with 4x USB 3.0 ports, 1x RJ45 Ethernet LAN (Gigabit), 65W power brick, power cables - Elo P/N: E955492; 0702L - Elo P/N: E796382
Data from elotouch.com product page and its specification table, checked 2026-10-27.
Lifecycle
- Sales status
- Current
- Status basis
- Listed as a current product on elotouch.com; no end-of-life notice found on the product page
