Elo Touch · POS computer

Elo Touch 15-inch (16:9) E-Series 2

Purpose-built for point of sale, the E-Series 2 offers a 15.6-inch touchscreen display, Intel’s 8th generation Celeron processor and an integrated expansion hub to connect the peripherals you need.

Operating systemNo OS; Windows 10 IoT Enterprise LTSC 64-bit
Display15.6'' diagonal, Active matrix TFT LCD (LED)
SealingTouchscreen sealed to sub-bezel; Touchscreen sealed to LCD

Datasheet at Elo Touch Product page at Elo Touch

Runs Raptool apps in the Raptool Client, with access to the scanner, camera, RFID and printers, online and offline. Scanner apps

Overview

Purpose-built for point of sale, the E-Series 2 offers a 15.6-inch touchscreen display, Intel’s 8th generation Celeron processor and an integrated expansion hub to connect the peripherals you need.

The E-Series 2 includes USB-C connectivity, allowing you to easily connect a customer-facing display - providing touch, data and power with just one cable.
Seamlessly attach any combination of up to four peripherals to the edge of the touchscreen creating a bespoke solution. And, you can add or move them later as your needs change!
Integrated into the base of the stand, the expansion hub allows you to connect all of the POS peripheral support you need. From cash drawers and printers to barcode scanners and payment devices — there is connectivity to cover it all.
The E-Series 2 utilizes the reliability-tested performance and security of Intel’s 8th Generation Celeron processor, integrated Trusted Platform Modules and the Windows 10 operating system. For added flexibility, the E-Series 2 offers models with no OS - all pretested with Linux SuSE, Ubuntu and Red Hat operating systems.
Rigorously tested and backed by a three-year warranty. With splash-proof housing and a rugged retail-hardened design, the E-Series 2 can withstand the adverse conditions associated with most commercial environments.

Best for: POS Systems for Restaurants

Specifications

Technical

Part Number(s): No OS - E135925; Win 10 - E136131
Enclosure Color: Black
Touch Technology & Capacity: PCAP (TouchPro® Projected Capacitive) - 10 Touch
Processor: Intel Celeron® Processor J4125 (4M Cache, up to 2.7 GHz)
Graphics: Intel UHD Graphics 600
BIOS: AMI
Memory (RAM): 4GB 2666MHz DDR4 SO-DIMM on 1 of 2 slots; (Expandable to 8GB maximum on 2 slots)
Storage: 128GB M.2 SATA SSD, 80 TBW
TPM: 2.0
Diagonal Size: 15.6'' diagonal, Active matrix TFT LCD (LED)
Aspect Ratio: 16:9
Active Area: 13.55" x 7.62" / 344.2 mm x 193.5 mm
Resolution: 1366 x 768 @ 60Hz
Number of Colors: 266,144
Brightness (typical): LCD Panel: 220 nits; PCAP: 187 nits
Response Time-total (typical): 10 msec
Contrast Ratio: 400:1
Viewing Angle: Horizontal: 45°/45° or 90° total / Vertical: 15°/35° or 50° total
USB Ports: 3 x USB 3.0 (1 on display head, 2 on I/O); 2 x USB 2.0 (on I/O); 4 x Micro USB 2.0 (on display head)
Powered USB: 1 x 24V on I/O; 2 x 12V on I/O
Ethernet Port: 1 x LAN RJ45 (Gigabit)
Serial Ports: 2 x RJ45
Cash Drawer Port: 12V/24V Cash Drawer Port on I/O (EPSON Pinout, 24V default; selectable by internal switch)
Additional Video Out: 1 x Full-function USB-C (Power up to 27W, USB 3.0, Display Port)
Audio Ports: 1 x 3.5 mm headset jack
Speakers: 2 x 2W internal speakers
OS: No OS; Windows 10 IoT Enterprise LTSC 64-bit
Languages: Windows 10 - 36 Language groups
Power Supply: External 24VDC universal-type power supply brick; AC input voltage: 100-240 VAC; Input frequency: 50-60 Hz; Maximum output power: 180W
Power Consumption (Typical): 24W; Sleep:
Dimensions: 15.2" x 14.54" x 8.71" / 386.2 mm x 369.3 mm x 221.2 mm
Shipping Box Dimensions: 18.19" x 11.77" x 18.5" / 462 mm x 299 mm x 470 mm
Weight (Unpackaged): 10.4 lbs / 4.7 kg
Weight (Packaged): 15.2 lbs / 6.9 kg
Operating Temperature: 0°C to 35°C / 32°F to 95°F
Storage Temperature: -20°C to 60°C / -4°F to 140°F
Humidity: Operating: 20% to 80%; Storage: 5% to 95% (38.7℃ max wet bulb temperature)
Regulatory approvals and declarations: UL/cUL, FCC, TUV, CE, CB, NOM, S-Mark, UKCA, China CCC
Real-Time Clock: CR2032 lithium metal battery
MTBF: 50,000 hours demonstrated
Mounting Options: 75mm VESA mount
Warranty: 3-year
Extended Service Options: 4 year warranty coverage - Elo P/N: E819598; 5 year warranty coverage - Elo P/N: E819795; 3 year warranty coverage + AUR - Elo P/N: E820186; 4 year warranty coverage + AUR - Elo P/N: E820388; 5 year warranty coverage + AUR - Elo P/N: E820582
Sealability: Touchscreen sealed to sub-bezel; Touchscreen sealed to LCD
Power Cables: North American and European power cables included
Other Features: Serviceable internal components.; Kensington lock.
What's in the Box: E-Series 2; North America Power Cord; EU Power Cord; Power Adapter – 180W; Cable Management Kit; Quick Installation Guide (QIG)
Upgrade Options: 4GB 2666 MHz DDR4 Memory SO-DIMM - Elo P/N: E264186; M.2 SATA 128GB SSD – Elo P/N: E206352; M.2 SATA 256GB SSD – Elo P/N: E206556
Optional Peripherals: Magnetic Stripe Reader (MSR) – Elo P/N: E001002; Fingerprint Scanner – Elo P/N: E134286; 10" LCD Customer-facing Display (10 touch) – Elo P/N: E155834 (requires both the display mount kit E835969 and Elo 2ft USB-C cable E969524)); 10" LCD Customer-facing Display (no touch) – Elo P/N: E324341 (requires both the display mount kit E835969 and Elo 2ft USB-C cable E969524)); 1302L Customer-facing Display (10 touch) – Elo P/N: E683595 (requires both the display mount kit E835969 and Elo 2ft USB-C cable E969524)); EMV Cradle for MagTek eDynamo - Elo P/N: E375343; EMV Cradle for Ingenico RP457c (with Audio Jack, BT and USB) - Elo P/N: E586981; EMV Cradle for Ingenico RP457c (with BT and USB) - Elo P/N: E710930; Status Light (Micro-USB Connectivity) - Elo P/N: E466847
Stands, Mounts & Kits: Shelf Mount Bracket (75mm or 100mm VESA) - Elo P/N: E043382; Floor Stand (75mm or 100mm VESA) - Elo P/N: E048069; Pole Mount – 6 inch (75mm or 100mm VESA) - Elo P/N: E047458; Pole Mount – 12 inch (75mm or 100mm VESA) - Elo P/N: E047663; Pole Mount – 18 inch (75mm or 100mm VESA) - Elo P/N: E047864; Pole Mount Bracket (75mm or 100mm VESA) - Elo P/N: E045151; Rear-facing Display Mount - Elo P/N: E835969 (Requires authorized 2ft USB-C cable); Power Brick Kit, 24V 180W - Elo P/N: E845269; Elo 2ft authorized USB-C cable - Elo P/N: E969524

Data from elotouch.com product page and its specification table, checked 2026-10-27.

Lifecycle

Sales status: Current
Status basis: Listed as a current product on elotouch.com; no end-of-life notice found on the product page
