Zebra TC5X Series Mobile Computers

Specifications

Dimensions

TC52x/TC52ax/TC57x with SE4720: 6.10 in. L x 2.9 in. W x 0.73 in. H 155 mm L x 75.5 mm W x 18.6 mm H TC52ax with SE55: 6.26 in. L x 2.9 in. W x 0.73 in. H 159 mm L x 75.5 mm W x 18.6 mm H

Weight (with battery)

TC52x/TC57x: 8.8 oz./249 g TC52ax : (SE4720) 9.2 oz. /260 g TC52ax: (SE55) 9.4 oz./266 g

Display

5.0 in. Full High Definition (1920 x 1080); LED backlight, optically bonded to touch panel

Imager Window

Corning™ Gorilla™ Glass

Touchpanel

Dual mode capacitive touch with stylus, bare or gloved fingertip input (stylus sold separately); Corning Gorilla Glass; water droplet rejection; fingerprint resistant anti-smudge coating

Charging / power

Rechargeable Li-Ion, PowerPrecision+; > 15.48 Watt hours; > 4150 mAh, improved battery metrics for better battery management; fast charging (up to 2.4 A); Warm Swap battery mode up to two minutes (120 seconds); BLE battery optional

Expansion Slot

Accessible MicroSD supports up to 256 GB SDXC

SIM

TC57x only: 1 nano SIM; 1 eSIM

Network Connections

TC52x/TC52ax/TC57x: WLAN, WPAN (Bluetooth), USB 2.0, High Speed (Host and Client) TC57x only: WWAN

Notifications

Audible tone; multi-color LEDs; haptic feedback

Keyboard / keys

On-screen keypad and enterprise keyboard

Voice and Audio

Three microphones with noise cancellation; vibrate alert; front facing speaker; Bluetooth wireless headset support; high quality speaker phone; PTT headset support; cellular circuit switch voice; HD voice; Super-wideband (SWB) and Fullband (FB) audio; 3.5mm audio jack

Keyboard / keys

Four programmable buttons: dual dedicated scan buttons, dedicated push-to-talk button and volume up/down buttons

Processor

TC52x/TC57x/TC52ax: Qualcomm Snapdragon™ 660 octa-core, 2.45 GHz

Operating system

TC52x: Upgradeable to Android 14 TC57x: Upgradeable to Android 14 TC52ax: Upgradeable to Android 14

RAM / storage options

TC52x/TC57x: 4GB RAM/32GB UFS Flash TC52ax: 4GB RAM/64GB UFS Flash

Security

FIPS 140-2 Validated (ISO 19790) and Common Criteria certified (ISO 15408); FIPS 140-2 cryptography can be enabled on select configurations through a custom SKU request; Supports Secure Boot and Verified Boot.

Operating temperature

-4°F to 122°F/-20°C to 50°C

Storage temperature

-40°F to 158°F/-40°C to 70°C

Humidity

5% to 95% non-condensing

Drop specification

Multiple 6 ft./1.8 m drops to concrete with the rugged boot accessory per Mil STD 810 G; multiple 4 ft./1.2 m drops to tile over concrete -10°C to 50°C/14°F to 122°F

Tumble specification

500 1.6 ft./0.5 m tumbles, meets or exceeds IEC tumble specification

IP / sealing

IP68 and IP65 with battery per applicable IEC sealing specifications

Electrostatic Discharge (ESD)

+/- 15 kV air discharge; +/- 8 kV direct discharge; +/- 8 kV indirect discharge

Light Sensor

Automatically adjusts display backlight brightness

Magnetometer

eCompass automatically detects direction and orientation

Motion Sensor

3-axis Accelerometer with MEMS Gyro

Pressure Sensor

Automatically detects altitude information for locating (TC57x only)

Proximity Sensor

Automatically detects when the user places the handset against head during a phone call to disable display output and touch input

Scan engines / capture options

All models: SE4720 1D/2D Scan Engine TC52ax only: SE55 Advanced Range 1D/2D Scan Engine with IntelliFocus

Cameras

All models: Front — 5 MP; TC52x/TC57x Rear — 13 MP autofocus; flash LED generates balanced white light; supports Torch mode; TC52ax Rear — 13 MP Phase Detection Autofocus (PDAF); flash LED generates balanced white light; Torch mode

NFC

ISO 14443 Type A and B; FeliCa and ISO 15693 cards; P2P mode (up to A10 only) and Card Emulation via Host; Card Emulation via UICC (WWAN terminals only)

Radio Frequency Band

Supports VoLTEs, Carrier Aggregation up to 3DL AT&T FirstNet Ready certification Verizon PNTM certification LTE FDD: 700/800/850/900/1800/1900/AWS/2100/2600 (28,13,14,12,17/19,20/5,26/8/3/2,25/4,66/1/7); LTE TDD: 1900/2300/2500 (39/40/41,38); UMTS/HSPA/HSPA+: 850/900/AWS/1900/2100 (5/8/4/2/1); GSM/GPRS/EDGE: 850/900/1800/1900

Location / GPS

TC57x only: Autonomous, Concurrent GPS; GLONASS; Gallileo; BeiDou and A-GPS; supports IZAT™ XTRA

Multimedia

Wi-Fi Multimedia™ (WMM) and WMM-PS; TSPEC

Radio

IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/mc/ax 4 ; 2x2 MU-MIMO; Wi-Fi™ certified; Dual Band Simultaneous; IPv4, IPv6

Data Rates

5GHz: 802.11a/n/ac/ax 4 — 20MHz, 40MHz, 80MHz - up to 1201 Mbps; 2.4GHz: 802.11b/g/n/ax 4 — 20MHz up to 286.8 Mbps

Operating Channels

Channel 1-13 (2412-2472 MHz): 1,2,3,4,5,6,7,8,9,10,11,12,13 Channel 36-165 (5180-5825 MHz): 36,40,44,48,52 56,60,64,100,104,108,112,116,120,124,128,132,136, 140,144,149,153,157,161,165 Channel Bandwidth: 20, 40, 80 MHz Actual operating channels/ frequencies and bandwidths depend on regulatory rules and certification agency.

Security and Encryption

WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP, and AES); WPA3 Personal (SAE); WPA/WPA2 Enterprise (TKIP and AES); WPA3 Enterprise (AES) — EAP-TTLS (PAP, MSCHAP, MSCHAPv2); EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, LEAP and EAP-PWD; WPA3 Enterprise 192-bit mode (GCMP-256) — EAP-TLS; Enhanced Open (OWE)

Certifications

Wi-Fi Alliance Certifications: Wi-Fi CERTIFIED n; Wi-Fi CERTIFIED ac; Wi-Fi CERTIFIED 6 (TC52ax only); Wi-Fi Enhanced Open; WPA2-Personal; WPA2-Enterprise; WPA3-Personal; WPA3-Enterprise (includes 192-bit mode); Protected Management Frames; Wi-Fi Agile Multiband; WMM; WMM-Power Save; WMM-Admission Control; Voice-Enterprise; Wi-Fi Direct

Fast Roam

PMKID caching; Cisco CCKM; 802.11r (OTA); OKC

Bluetooth

Class 2, Bluetooth v5.0 (TC52x/TC57x) and Bluetooth v5.1 (TC52ax); Bluetooth Low Energy

Power

Rechargeable Li-Ion, PowerPrecision+; > 15.48 Watt hours; > 4150 mAh, improved battery metrics for better battery management; fast charging (up to 2.4 A); Warm Swap battery mode up to two minutes (120 seconds); BLE battery optional

Keypad

On-screen keypad and enterprise keyboard

Buttons

Four programmable buttons: dual dedicated scan buttons, dedicated push-to-talk button and volume up/down buttons

CPU

TC52x/TC57x/TC52ax:; Qualcomm Snapdragon™ 660 octa-core, 2.45 GHz

Memory

TC52x/TC57x: 4GB RAM/32GB UFS Flash; TC52ax: 4GB RAM/64GB UFS Flash

Operating Temp.

-4°F to 122°F/-20°C to 50°C

Storage Temp.

-40°F to 158°F/-40°C to 70°C

Drop Specifications

Multiple 6 ft./1.8 m drops to concrete with the rugged boot accessory per Mil STD 810 G; multiple 4 ft./1.2 m drops to tile over concrete -10°C to 50°C/14°F to 122°F

Sealing

IP68 and IP65 with battery per applicable IEC sealing specifications

Scanning

All models: SE4720 1D/2D Scan Engine; TC52ax only: SE55 Advanced Range 1D/2D Scan Engine with IntelliFocus

Camera

All models: Front — 5 MP; TC52x/TC57x Rear — 13 MP autofocus; flash LED generates balanced white light; supports Torch mode; TC52ax Rear — 13 MP Phase Detection Autofocus (PDAF); flash LED generates balanced white light; Torch mode

GPS

TC57x only: Autonomous, Concurrent GPS; GLONASS; Gallileo; BeiDou and A-GPS; supports IZAT™ XTRA
