Elo Touch 5553L 55" (4K) Interactive Digital Signage

Elo's 55-inch, 4K touchscreen display adds interactivity to any environment. Perfect for everything from endless aisle and brand experiences to collaborative meetings, conferencing and whiteboarding,

Display54.6'' diagonal, Active matrix TFT LCD (LED)

Datasheet at Elo Touch Product page at Elo Touch

Shows Raptool apps running in the Raptool Client on a connected Android, iOS, Windows or Mac device. Scanner apps

Overview

Elo's 55-inch, 4K touchscreen display adds interactivity to any environment. Perfect for everything from endless aisle and brand experiences to collaborative meetings, conferencing and whiteboarding, the 5553L offers a sleek, slim design built to withstand the rigors of continuous commercial use. Easily turn the display into a powerful, 55-inch, all-in-one, life-size tablet by adding an Elo computer module. Available with either PCAP (with anti-glare or clear glass with anti-friction) or infrared (with anti-glare) touch technologies, the professional-grade, large-format display integrates easily into any environment.

Whether you are looking for an interactive display for a department store, restaurant or corporate environment, Elo's 5553L offers the flexibility for a variety of applications. Explore how the 5553L can support both collaboration and interactive signage installations.
Not only do high-traffic environments demand interaction, but conference and huddle rooms do as well. Interactive displays expand collaboration capabilities between the presenter and his or her audience, helping deliver concepts beyond what a whiteboard and dry erase marker can do.
Designed for conference and huddle rooms, the Conference Camera delivers full HD video with wide viewing angles, an adjustable slider and 30° tilt that supports both vertical and horizontal adjustment. Choose whether you want to mount it on the top or on the side of your interactive display and simply attach, orient the camera and you’re ready to start your meeting. The Conference Camera is compatible with all major web conferencing applications, including Microsoft Teams, Zoom, Cisco Webex, GoToMeeting and BlueJeans.
The user-friendly annotation and whiteboarding software provides corporate environments with a full set of features— from multi-user writing and drawing to handwriting recognition, graphical input and full multi-media integration and capture, the 5553L has the durability your environment demands. Choose between a stylus or your finger and start collaborating.
The commercial-grade computer module transforms Elo's touchscreen into a powerful, all-in-one, touch computer platform with compatibility with most content-management servers. Running Intel Core™ 7th-Generation CPUs and enhanced graphics engine, the ECMG4s make field installation and maintenance easy with no external cables required.

Specifications

Technical

Part Number(s): Infrared (with anti-glare) - E628244; TouchPro PCAP (with anti-glare) - E628053; TouchPro PCAP (clear with anti-friction) - E914973
Enclosure Color: Black
Touch Technology & Capacity: PCAP (TouchPro® Projected Capacitive) - 40 Touch; Infrared - 20 Touch
Diagonal Size: 54.6'' diagonal, Active matrix TFT LCD (LED)
Active Area: 47.62" x 26.79" / 1209.6 mm x 680.4 mm
Aspect Ratio: 16:9
Resolution: 3840 x 2160 @ 60hz
Other Supported Resolutions: 640 x 480 60Hz; 720 x 480 60Hz; 720 x 576 50Hz; 800 x 600 56/60Hz; 1024 x 768 60Hz; 1280 x 720 50, 60Hz; 1280 x 960 60Hz; 1280 x 1024 60Hz; 1366 x 768 60Hz, 60Hz RB; 1440 x 900 60Hz, 60Hz RB; 1680 x 1050 60Hz, 60Hz RB; 1920 x 1080 50, 60Hz; 3840 x 2160 60Hz – Native resolution
Viewing Angle: Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total
Number of Colors: 10-bit (1.07 billion)
Brightness (typical): LCD Panel: 500 nits; IR: 450 nits; TouchPro PCAP: 430 nits
Response Time-total (typical): 8 msec
Contrast Ratio: 1100:1
On Screen Display: Let’s Get Started: Language Selection, Time Setting, Time Zone; Video Source Select: HDMI-1, HDMI-2, HDMI-Side, DisplayPort, Internal-PC, Conference; Video Settings: Video Port Discovery, Brightness, Contrast, Black Level, Sharpness and Aspect Ratio can be selected; Color Settings: Color Temperature, Color Sensor, User Preset (for color), Picture Modes and HDMI Full Range are available in this menu; Audio Settings: Audio Output, Mute, Volume selection are available here; Power: Power Loss Behavior, Power Lock, Energy Star Mode, Power Savings Light options are available here; Time: Time Set, On/Off Schedule; OSD Settings: Recall Defaults, OSD Timer, OSD Language, OSD Lock and OSD Portrait Rotation; Information: Monitor, Temperature and Help & Support are available here; Conference: Screen Share Enable, Conference Hub Power Behavior; See user manual for full details.
I/O Ports: Back:; HDMI x2; USB 3.0 Type B; RJ45 OSD Remote; DISPLAYPORT 1.4; 3.5mm TRS jack for Serial RS232; 3.5mm Audio Headphones Line-out; Side:; HDMI x1; USB 3.0 Type A; Power Button; Video Source Selection; On Screen Display Button
Video: 3x HDCP-capable HDMI on Type A connector; DisplayPort 1.4 connector; Input Video Horizontal Sync frequency range: 121.8 - 140 KHz; Input Video Vertical Sync (frame rate) frequency range: 47 - 63 Hz
Headphone Output Connector: 3.5 mm TRS jack
Speakers: 2 x 10 W stereo speakers
Power: Input power connector: IEC 60320-C13; Input power signal specifications: 100-240VAC 50/60Hz
Maximum Operating Time: 24 hours/day
Power Consumption (Typical): TouchPro (monitor + AC/DC adapter); ON: 111.87 W; ON (with ECMG4): 125.12 W; SLEEP: 1.52 W; OFF: 0.38 W; IR (monitor + AC/DC adapter); ON: 110.72 W; ON (with ECMG4): 124.23 W; SLEEP: 1.52 W; OFF: 0.38 W
Dimensions: TouchPro: 50.07" x 29.24" x 3.15" / 1271.8 mm x 742.6 mm x 80 mm; IR: 50.07" x 29.24" x 3.54" / 1271.8 mm x 742.6 mm x 89.8 mm
Shipping Box Dimensions: 55.12" x 36.61" x 9.61" / 1410 mm x 930 mm x 244 mm
Weight (Unpackaged): TouchPro:; With ECMG4: 85.8 lbs / 38.9 kg; Without ECMG4: 81.1 lbs / 36.8 kg; IR:; With ECMG4: 85.2 lbs / 38.65 kg; Without ECMG4: 80.6 lbs / 36.55 kg
Weight (Packaged): TouchPro:; Without ECMG4: 102.5 lbs / 46.47 kg; IR:; Without ECMG4: 101.9 lbs / 46.22 kg
Operating Temperature: Portrait/Landscape/Tilt (≤15°) Mode: 0°C to 40°C / 32°F to 104°F; Tabletop Mode: 0° C to 35° C / 32° F to 95° F
Storage Temperature: Portrait/Landscape/Tilt (≤15°) Mode: -20°C to 60°C / -4°F to 140°F; Tabletop Mode: -20° C to 60° C / -4° F to 140° F
Humidity: Operating: 20% to 80%; Storage: 10% to 95% (38.7° C max wet bulb temperature)
Mounting Options: VESA MOUNT PER MIS-F, 400 x 400mm, M6; VESA MOUNT PER MIS-F, 600 x 600mm, M8; See dimensional drawings for details
MTBF: 50,000 hours demonstrated
Warranty: 3-year with AUR included
Extended Service Options: 4 year warranty coverage + AUR - Elo P/N: E740135; 5 year warranty coverage + AUR - Elo P/N: E740330; 3 year warranty coverage + OSE - Elo P/N: E740527; 4 year warranty coverage + OSE - Elo P/N: E740728; 5 year warranty coverage + OSE - Elo P/N: E740918
Regulatory approvals and declarations: UL 62368-1; FCC (US); cUL, IC (Canada); CB (International safety) (IEC/EN60950-1+IEC/EN62368-1); CE (Europe); RCM (Australia); VCCI (Japan); CCC (China) (for TouchPro version only); IK07 and UL60950 for ball drop test
Energy Star: Energy Star 8.0
Other Features: Ambient Light Sensor - changes panel color to match ambient light, Auto Wake
What's in the Box: Quick Install Guide; HDMI 2.0 cable; USB 3.0 cable (Type A plug to Type B plug); power cable, IEC 60320-C13 to NA plug; power cable, IEC 60320-C13 to EU/KR plug; power cable, IEC 60320-C13 to UK plug; Serial 3.5mm male to Serial DB9 female cable; Energy label according to EU Regulation 1062/2010
IDS Optional Accessories: 3D Camera - Elo P/N: E134699; Webcam - Elo P/N: E201494; 2D Barcode Scanner (SE4720) – Elo P/N: E384627; 2D Barcode Scanner (SE4107) – Elo P/N: E245047; Magnetic Stripe Reader – Elo P/N: E001002; NFC/RFID Reader – Elo P/N: E001004; Fingerprint Scanner – Elo P/N: E134286; Wired OSD Remote - Elo P/N: E483757; Passive Stylus - Elo P/N: E727568; Replacement Cable Kit - Elo P/N: E283066; i5-7500 ECMG4 with No OS - Elo P/N: E227895; i5-7500 ECMG4 with Win10 (LTSC) - Elo P/N: E228087; Wallmount - Elo P/N: E727774; Status Light (Micro-USB Connectivity) - Elo P/N: E644767; Elo Backpack® 4 (Value Model) - Elo P/N: E393754; Elo Backpack® 4 (Standard Model) - Elo P/N: E393359; RFID - Elo P/N: E673037; 4K Conference Camera - Elo P/N: E988153; Elo Edge Connect™ Speaker Bar (Black) - Elo P/N: E894719; Elo Edge Connect™ Speaker Bar (White) - Elo P/N: E133780

Data from elotouch.com product page and its specification table, checked 2026-10-27.

Lifecycle

Sales status: Discontinued
Replacement: 5554L
Status basis: elotouch.com lists it as replaced by 5554L
