Datalogic Memor K20-25
The Memor K20-25 is the ultimate solution for mobile workers who need a compact, efficient, and rugged device with the familiarity of a physical keypad. Memor K20-25: Handheld Computers.
- Operating systemAndroid 13 with GMS , upgradeable to Android 15
- Display4-inch IPS WVGA resolution 800 x 480 LED backlight Touch Screen: 5 points multi-touch capacitive panel with…
- Scanning2D Ultra slim area imager (supports 1D / 2D codes) Halogen™ DE2102-HP: Resolution: Megapixel (1280 x 800…
- BatteryRemovable battery pack 4850 mAh with rechargeable Lithium batteries
- DropWithstands drops from 1.5 m / 5 ft to concrete according to MIL-STD-810H Device with rubber boot withstands…
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Specifications
Specifications
- Local Area Network (WLAN)
- IEEE 802.11 ac/a/b/g/n/r/d/e/i/k/v/w; Frequency range: Country dependent, typically 2.4 GHz and 5 GHz bands
- Battery / runtime
- Removable battery pack 4850 mAh with rechargeable Lithium batteries
- Drop specification
- Withstands drops from 1.5 m / 5 ft to concrete according to MIL-STD-810H Device with rubber boot withstands drops from 1.8 m / 6 ft to concrete according to MIL-STD-810H
- Particulate and Water Sealing
- IP65
- Temperature
- Operating: -20 a 50°C / da -4 a 122°F Storage/Transport: -30 to 70 ºC / -22 to 158 ºF
- Ports / interfaces
- USB-C: High Speed USB 2.0 OTG
- Dimensions
- 16.6 x 6.9 x 1.7 cm / 6.5 x 2.7 x 0.67 in
- Display
- 4-inch IPS WVGA resolution 800 x 480 LED backlight Touch Screen: 5 points multi-touch capacitive panel with Panda hardened glass
- Keyboard / keys
- Backlighted 24 keys keyboard, plus two side scan keys and one programmable side key
- Weight
- With Battery: 265 g / 9.4 oz
- Cameras
- Resolution: 13 MP; Illumination: LED flash; Lens: Auto focus
- Scan engines / capture options
- 2D Ultra slim area imager (supports 1D / 2D codes) Halogen™ DE2102-HP: Resolution: Megapixel (1280 x 800 pixels) Depth of Field: 4 to 90 cm / 1.6 to 35 in, depending on bar code density and type Aiming: 650nm VLD; Field of View: 42°H x 26°V
- Minimum Element Width
- Halogen™ DE2102-HP: 1D Linear: 0.0635 mm / 2.5 mils PDF: 0.0762 mm / 3 mils Data Matrix: 0.152 mm / 6 mils
- RAM / storage options
- System RAM: 4 GB; eMMC Flash: 64 GB
- Microprocessor
- 2 GHz Octa-core
- Operating system
- Android 13 with GMS , upgradeable to Android 15
- Warranty
- 1-Year Factory Warranty
