Chainway MC51S Mobile Computer
A rugged Android 16 mobile computer built on a Qualcomm long-lifecycle platform, the MC51S delivers up to 2.4GHz processing performance with an optional 2.8GHz platform. It features a 6-inch HD display, IP67 protection, barcode scanning, NFC, and optional UHF RFID for efficient enterprise data capture.
- Operating systemAndroid 16
- Display6" display, 1440 x 720; optional 2160 x 1080 FHD version
- Battery5000mAh removable main battery, support QC3.0 and RTC Support Battery Management System Hot-swap
- SealingIP67 per IEC sealing specifications
- DropPassed 1.5 m/4.92 ft. drop test to MIL-STD-810H standard
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Videos
Specifications
Platform
- Operating system
- Android 16
- Processor
- Octa-core 2.8GHz
- RAM / storage options
- 4GB + 64GB; optional up to 8GB + 256GB
Display
- Display size
- 6" display, 1440 x 720; optional 2160 x 1080 FHD version
- Touch panel
- Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported
- Keyboard / keys
- 1 Power key, 2 scan keys, 1 volume (+/-) keys, 1 multifunctional key
Data capture
- Cameras
- 5MP 16MP Autofocus with flash 2D Scanner
Power
- Battery / runtime
- 5000mAh removable main battery, support QC3.0 and RTC Support Battery Management System Hot-swap
- Charging / power
- 1-30dBm, step 1dB
Connectivity
- Wi-Fi / WLAN
- Supports 802.11 a/b/g/n/ac/ax; fast roaming supported
- Cellular / WWAN
- 2G: GSM/EDGE/GPRS(850/900/1800/1900) 3G: WCDMA (B1/B2/B4/B5/B8) 4G: LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B20/B25/        B26/B28A/B28B;        LTE-TDD: B34/B38/B39/B40/B41
- Bluetooth
- Bluetooth 5.1, headset support
- Location / GPS
- GPS, BeiDou, GLONASS, and Galileo AGPS supported 161.0 × 77.8 × 15.5mm / 6.34 × 3.06 × 0.61in.
- Ports / interfaces
- USB 3.0 Type-C with OTG and water-drop detection; bottom contacts: 2-pin for charging; rear contacts: 2-pin for handle button extension; 12-pin for optional expansion(optional); 12-pin contacts for UHF back clip and battery charging
Rugged
- IP / sealing
- IP67 per IEC sealing specifications
- Drop specification
- Passed 1.5 m/4.92 ft. drop test to MIL-STD-810H standard
- Tumble specification
- 1000 x 0.5m / 1.64ft. falls, IEC compliant
- Operating temperature
- -4° F to 122° F (-20° C to 50° C)
- Storage temperature
- -40° F to 158° F (-40° C to 70° C)
- Humidity
- 5%RH - 95%RH non condensing
Size
- Weight
- Standard version: 297g / 10.48oz. (device with battery); Built in UHF version: 323g / 11.39oz. (device with battery); UHF version: 600g / 21.16oz. (including handle, back clip)
- Dimensions
- Standard version: 161.0 x 77.8 x 15.5mm / 6.34 x 3.06 x 0.61 in.; Built in UHF version: 161.0 × 77.8 × 15.5mm (Thickest Part: 29.2mm) / 6.34 × 3.06 × 0.61in. (Thickest Part: 1.15in.); UHF version: 165.0 x 83.8 x 138.0mm / 6.50 x 3.30 x 5.43 in.
