Chainway C63 Mobile Computer
A rugged Android 13 mobile computer, the C63 offers flexible 27/37/47-key layouts and optional ultra-long-range barcode scanning. Its 6700mAh main battery and optional 5000mAh handle battery support hot-swapping for nonstop operation in demanding industrial environments.
- Operating systemAndroid 13
- Display4-inch high definition display, 800*480
- Battery6700 mAh removable main battery, 5000 mAh optional pistol battery, support QC3.0 and RTC; Built in 50mAh…
- SealingIP67 per IEC sealing specifications
- DropMultiple 1.5 m / 4.92 ft. drops to the concrete across the operating temperature range
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Videos
Specifications
Platform
- Operating system
- Android 13
- Processor
- Octa-core, 2.0 GHz
- RAM / storage options
- UFS, 4GB + 64GB
Display
- Display size
- 4-inch high definition display, 800*480
- Touch panel
- Multi-touch panel, gloves and wet hands supported
- Keyboard / keys
- Main keyboard (Optional) : 27 keys / 37 keys / 47 keys; Side keys: 2 scan keys + 2 volume keys + 1 user-defined key
Data capture
- Cameras
- Rear 13 MP Autofocus with flash
Power
- Battery / runtime
- 6700 mAh removable main battery, 5000 mAh optional pistol battery, support QC3.0 and RTC; Built in 50mAh backup battery, pistol battery with meter; supporting battery hot swap, improving reliability and ensuring user data security Standby: up to 680 hours (only main battery ; WiFi: up to 560h; 4G: up to 560h) Continuous use: over 12 hours (depending on user environment) Charging time: 3.5 hours (charge device by standard adaptor and USB cable)
Connectivity
- Wi-Fi / WLAN
- Support 802.11 a/b/g/n/ac/ax-ready/d/e/h/i/k/r/v, 2.4G/5G dualband, IPV4, IPV6, 5G PA; Fast roaming: PMKID caching, 802.11r, OKC Operating Channels: 2.4G(channel 1~13), 5G(channel 36,40,44,48,52,56,60,64,100,104,108,112,116,120, 124,128,132,136,140,144,149,153,157,161,165), Depends on local regulations Security and Encryption: WEP, WPA/WPA2-PSK(TKIP and AES), WAPI-PSK—EAP-TTLS, EAP-TLS, PEAP-MSCHAPv2, PEAP-LTS, PEAP-GTC,etc.
- Cellular / WWAN
- 2G: 850/900/1800/1900 MHz 3G: CDMA EVDO: BC0        WCDMA: 850/900/1700/1900/2100MHz        TD-SCDMA: A/F(B34/B39) 4G: B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B20/B28/ B38/ B39/B40/B41 *C63 models being manufactured for Turkish Market, do not include WWAN and SIM slot option.
- Bluetooth
- Bluetooth 5.1
- Location / GPS
- GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna
- Ports / interfaces
- USB Type-C, USB 3.1, OTG, extended thimble
Rugged
- IP / sealing
- IP67 per IEC sealing specifications
- Drop specification
- Multiple 1.5 m / 4.92 ft. drops to the concrete across the operating temperature range
- Tumble specification
- 1000 x 0.5 m / 1.64 ft. falls at room temperature
- Operating temperature
- -4℉to 122℉ / -20℃ to 50℃
- Storage temperature
- -40℉ to 158℉ / -40℃ to 70℃
- Humidity
- 5% RH to 95% RH (non condensing)
Size
- Weight
- 385g / 13.58oz. (device with battery) 571g / 20.14oz. (device with pistol and battery)
- Dimensions
- 203.50 x 72.8 x 160 mm / 8.01 x 2.87 x 6.30in. (with pistol) 203.50 x 72.8 x 34.8 mm / 8.01 x 2.87 x 1.37in. (without pistol)
