Unitech · Accessory
Unitech PA768 Wi-Fi Ver. (6th Gen)
Wi-Fi 6E｜Longevity 6490 Processor | 10m Reading Distance｜Hot Swappable 5100mAh UL certified Battery
- Operating systemAndroid 14 (upgradable to Android 16) Support Google ARcore
- Display6.3”, 20:9 Full-HD+ (2340X1080), High Resolution color Display High sunlight visibility- LCD backlight up to…
- BatteryHot Swappable 5100mAh UL certified smart battery / battery with cover in one piece
- SealingIP65 & IP68 per IEC 60529
- Drop1.8m drops with bumper to plywood over concrete at room temperature of 25°C per MIL-STD 810H
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Specifications
Platform
- Operating system
- Android 14 (upgradable to Android 16) Support Google ARcore
- Processor
- Qualcomm Snapdragon™ 6490 Processor, 64bits, Octa Cores up to 2.7GHz
- RAM / storage options
- RAM 6GB Flash 64GB UFS Flash (128GB option)
Display
- Display size
- 6.3”, 20:9 Full-HD+ (2340X1080), High Resolution color Display High sunlight visibility- LCD backlight up to 500nits
- Touch panel
- Gorilla Glass with Multi-Touch Capacitive Touch Panel, support stylus, glove (thickness ≤ 4mm), wet-finger Compatibility
Data capture
- Cameras
- 5 MP Front camera, 16 MP Rear Camera with LED flash and auto-focus function, Support Google ARcore
Power
- Battery / runtime
- Hot Swappable 5100mAh UL certified smart battery / battery with cover in one piece
Connectivity
- Wi-Fi / WLAN
- Wi-Fi 6E (802.11ax), 2.4GHz & 5GHz & 6GHz, support Dual-Band Simultaneous (DBS) IEEE 802.11a/b/g/n/ac/d/e/h/i/k/r/v/w/mc/ax (2x2 MU-MIMO) Security WPA3, WPA2, WPA & WEP
- Bluetooth
- Bluetooth® 5.2 , BLE 5, Class 1
Rugged
- IP / sealing
- IP65 & IP68 per IEC 60529
- Drop specification
- 1.8m drops with bumper to plywood over concrete at room temperature of 25°C per MIL-STD 810H
- Tumble specification
- 0.5m tumbles for 300 cycles / 600 drops
- Operating temperature
- -20°C to 55°C (-4°F to 131°F)
- Storage temperature
- -40°C to 70°C (-40°F to 158°F), without battery
- Humidity
- 5% ~ 95% (Non-Condensing)
Size
- Weight
- 297 g (with bumper & standard battery)
- Dimensions
- 167mm x 75.5mm x 17mm
Send a request
Get a quote for the PA768 Wi-Fi Ver. (6th Gen)
Tell us where you are and what you need.
Raptool does NOT sell hardware. We are a pure software company. The devices are sold by our hardware partners around the world. Your request goes straight to a partner in your country, and they send you the quote.
