Unitech · Barcode scanner
Unitech MS925 HC
The MS925 HC is a 2D pocket scanner with 1.5 drop spec and IP41 protection.
- Battery3.7V, 400mAh, Li-Polymer Battery 400mAh
- SealingIP41
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Videos
Specifications
Platform
- RAM / storage options
- 2MB (20,000 barcodes)
Data capture
- Scan range / decode distances
- (DOF PCS=80%) Decode Range | Near | Far 4 Mil Code 39 : 65 ~ 143mm 5 Mil Code 39 : 62 ~ 174mm 10 Mil Code 39 : 32 ~ 280mm 15 Mil Code 39 : 40 ~ 358mm 13 Mil UPC/EAN : 38 ~ 281mm 10 Mil QR Code : 47 ~ 193mm 15 Mil QR Code: 37 ~ 257mm 40 Mil QR Code: 72 ~ 424mm 6.67 Mil PDF417 : 64 ~ 131mm 10 Mil PDF417: 40 ~ 182mm 10 Mil Data Matrix : 53 ~ 171mm 20 Mil Data Matrix: 34 ~ 278mm
Power
- Battery / runtime
- 3.7V, 400mAh, Li-Polymer Battery 400mAh
Rugged
- IP / sealing
- IP41
- Operating temperature
- -10 ~ 50˚C
- Storage temperature
- -20 ~ 60˚C
- Humidity
- 0% ~ 95%RH (Non-condensing)
Size
- Weight
- 29.5g
- Dimensions
- W27.5 x L68.4 x H16.2 mm
