Unitech MS836B
100 m Connection | Keeps data even out of range | 30 hours operation time
- BatteryLithium-ion 2600mAh 18650 battery
- SealingIP42
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Specifications
Specifications
- 16MB Memory
- Inventory Mode
- Linear Laser Scanner
- Up to 100 times/sec
- RAM / storage options
- 16MB
- Key
- Trigger Key
- Sensor
- 1D Laser Engine
- Aiming Element
- Laser
- Ambient Light
- 0-100,000 Lux
- Scan Rate
- 100 times/ sec
- Skew Angle
- ±60°
- Optical Resolution
- ≥ 4mil（code 39）
- Scan range / decode distances
- 10mm-265mm(13 mil, EAN13, PCS=90%)
- Radio
- 2.4G Wireless Bluetooth V4.2 Class 2
- Wireless Coverage
- 2.4G 100 m( line of sight) Bluetooth: 10 m
- Protocol
- 2.4G USB Bluetooth HID, BLE ,SPP
- Host Interface supported
- USB Type C
- Memory Buffer
- 16MB
- Dimensions
- 174mm × 72mm × 96mm (L x W x H)
- Weight
- 216g
- Operation Mode
- Trigger Mode, Buffer Mode
- 1D Barcodes
- Industoal 2 of 5, Standard 25, Matrix 25, China post 25, Code 11, Codabar, MSI/plessey, UK/plessey, Code39 (Standard 39& Full ASCII Code 39)Code 32, Code 93, Code128, UPCA,UPCE, EAN13, EAN8,UPC/EAN add-on 2/5, ISBN,ISSN, GS1(RSS) RSS-14,LIMITED, EXPENDED, Include GS1 STACK
- Data Formatting
- Prefix, Suffix, Code ID
- Operation Voltage
- DC 5V
- Current Consumption
- Operation mode:＜120mA , Standby mode:＜85mA
- Indicator
- Buzzer LED light
- Battery / runtime
- Lithium-ion
- Battery / runtime
- 2600mAh 18650 battery
- Battery Charging time
- Fully charged in 5 hours
- Operating Time
- 30 hours (continuous working )
- Mechanical Shock
- 1.5m onto concrete (scanner only)
- Operating temperature
- -10°C to 50°C
- Storage temperature
- -20°C to 60°C
- Humidity
- 5-90% non-condensing
- IP / sealing
- IP42
- Items
- ■ 2.4G Dongle (PN:5500-900098G) ■ Hans-Free Stand (PN:5200-900014G)
- Regulatory Approvals
- CE, FCC, BSMI, VCCI
- The standard package contents
- ■ MS836B scanner ■ 2.4G Dongle ■ USB cable (Type C USB)
- Hardware Warranty
- 15 months
- Statement
- This product is warranted against defects in workmanship and materials for a period of fifteen months from the date of shipment. Accessories are warranted for three months to one year. Our different regions have varying warranty terms, and offer extended and comprehensive warranties, so please contact your local representative for more information.
