Opticon OPR-2001Z
OPR-2001Z barcode scanner ensures precise, efficient data collection for businesses needing dependable scanning solutions.
- SealingIP42
- Drop1.5 m / 5 ft drop onto concrete surface
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Specifications
Specifications
- Form factor
- Handheldscanner
- Connection
- Cabled
- Reading type
- 1D Laser
- Communication interface
- RS232 , USB
- RS232
- DB9 connector with external power supply
- USB
- ver. 1.1, HID/VCP, USB-A connector
- Light source
- 650 nm visible laser diode
- Scan method
- Bi-directional scanning
- Scan rate
- Up to 100 scans / second
- Drop specification
- 1.5 m / 5 ft drop onto concrete surface
- IP / sealing
- IP42
- Dimensions
- 56 x 151 x 31 mm / 2.20 x 5.94 x 1.22 in
- Dimensions
- 99 x 174 x 127 mm / 3.90 x 6.85 x 5.00 in (excl. scanner)
- Weight body
- Ca. 60 g / 2.1 oz (excl. cable)
- Weight Stand
- Ca. 90 g / 3.2 oz
- Product compliance
- CE, FCC, VCCI, RoHS, JIS-C-6802 Class 2, IEC60825-1 Class 2, FDA CDRH Class II, EN55022, EN55024
- Enclosed
- Stand (sold separately)
