Newland · Barcode scanner
Newland WD3 Badge Scanner
The WD3 is a feather-light badge barcode scanner that packs high performance in a compact yet sturdy design. You can use the scanner as a stand-alone device or wear it on a lanyard as a badge.
- Scanning1D Code 11, Code 128, Code39, GS1-128, AIM 128, ISBT 128, Codabar, Code 93, UPC-A,
- Battery300 mAh lithium-ion battery
- SealingIP65
- Drop1.2 m
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Specifications
Data capture
- Scan engines / capture options
- 1D Code 11, Code 128, Code39, GS1-128, AIM 128, ISBT 128, Codabar, Code 93, UPC-A,
- Scan range / decode distances
- 120 mm - 330 mm 125 mm - 240 mm 65 mm - 550 mm 120 mm - 240 mm 40 mm - 370 mm Field of View Horizontal 40°
Power
- Battery / runtime
- 300 mAh lithium-ion battery
- Charging / power
- 5 VDC ±5%
Connectivity
- Ports / interfaces
- USB
Rugged
- IP / sealing
- IP65
- Drop specification
- 1.2 m
- Operating temperature
- -20°C to 60°C (-4°F to 140°F)
- Storage temperature
- -40°C to 70°C (-40°F to 158°F)
- Humidity
- 5% to 95% (non-condensing)
Size
- Weight
- 53 g
- Dimensions
- 110.8(W) x 62.3(D) x 10.6(H) mm
Software & service
- Warranty
- 2 Years Warranty Standard 2 Years
