Newland · Barcode scanner
Newland HR33 Marlin AI Bluetooth
The HR33 Marling AI Bluetooth offers cutting-edge scanning capabilities and uninterrupted operation with its easily replaceable battery. See more.
- Scanning1D Code 11, Code 128, Code39, GS1-128(UCC/ENA-128), AIM 128, ISBT 128,Codabar,
- Battery2,600 mAh lithium-ion
- SealingIP52
- Drop1.8m drops to concrete
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Specifications
Data capture
- Scan engines / capture options
- 1D Code 11, Code 128, Code39, GS1-128(UCC/ENA-128), AIM 128, ISBT 128,Codabar,
- Scan range / decode distances
- 30 mm - 270 mm 20 mm - 245 mm 35 mm - 535 mm 35 mm - 215 mm Field of View Horizontal 48˚
Power
- Battery / runtime
- 2,600 mAh lithium-ion
- Charging / power
- 5 VDC ±5%
Connectivity
- Bluetooth
- 5.0
- Ports / interfaces
- USB-A, USB-KBW, USB-CDC, HID-POS
Rugged
- IP / sealing
- IP52
- Drop specification
- 1.8m drops to concrete
- Operating temperature
- -20°C to 50°C (-4°F to 122°F)
- Storage temperature
- -40°C to 70°C (-40°F to 158°F)
- Humidity
- 5% to 95% (non-condensing)
Size
- Weight
- Scanner: 210 g; Cradle: 340,5 g
- Dimensions
- Scanner: 117.5(L)×67.5(W)×144(H)mm; Cradle: 140(L)×90(W)×144.5(H)mm
Software & service
- Warranty
- 5 Years Comprehensive Service Contract 3 Years, 5 Years
