Newland EM1300
The EM1300 OEM Scan Engine offers a snappy & reliable engine for 1D symbologies. The high-performance CCD scan engine can easily be integrated into kiosks, ticketing machines and PDA's.
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Specifications
Specifications
- 1D
- All major 1D symbologies, including Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ISBN/ISSN, Code 93.
- Decode Rate
- 200 decodes per second (default)
- Field of View Horizontal
- 42°
- Illumination
- LED (622nm-628nm)
- Image Sensor
- 2500 CCD
- Minimal Print Contrast
- 25%
- Scan Angle Pitch
- ±65°
- Scan Angle Roll
- 30°
- Scan Angle Skew
- ±60°
- Scan Modes
- Handheld Mode, Sense Mode, Trigger Mode, Auto Mode, Interval Mode, Continuous Mode
- Scan Rate
- 300 scans per second
- Current @ 3.3VDC Operating
- 57 mA (Typical), 89 mA (max)
- Current @ 3.3VDC Sleep
- 11 mA
- Current @ 3.3VDC Standby
- 28 mA
- Dimensions
- 28.2(W) × 23.4(D) ×11.2(H) mm
- Housing
- ABS
- Charging / power
- 3.3 VDC ±5%
- Ports / interfaces
- TTL-232
- Power Consumption
- 188 mW
- Weight
- 6 g
- Ambient Light
- 0 to 100,000 lux
- Humidity
- 5% to 95% (non-condensing)
- Operating temperature
- -20°C to 60°C (-4°F to 140°F)
- Storage temperature
- -40°C to 85°C (-40°F to 185°F)
- Certifications Hardware
- CE EMC Class B, FCC Part15 Class B
- Warranty
- 2 Years
- Accessories Standard
- 75mm flexible flat cable (FFC), Software development board
- Part Number
- Description
- NLS-EM1300
- 1D CCD scan engine, Superior, 2.500 px (CCD), All-in-one housing, Processor, TTL232 interface with FFC (flexible flat cable)
- NLS-EM1300V2-GD
- 1D CCD scan engine, Superior, 2.500 px (CCD), All-in-one housing, Processor, TTL232 interface with FFC (flexible flat cable)
- Decode Rate
- 200 decodes per second (default)
- Field of View Horizontal
- 42°
- Illumination
- LED (622nm-628nm)
- Image Sensor
- 2500 CCD
- Minimal Print Contrast
- 25%
- Scan Angle Pitch
- ±65°
- Scan Angle Roll
- 30°
- Scan Angle Skew
- ±60°
- Current @ 3.3VDC Operating
- 57 mA (Typical), 89 mA (max)
- Current @ 3.3VDC Sleep
- 11 mA
- Current @ 3.3VDC Standby
- 28 mA
- Dimensions
- 28.2(W) × 23.4(D) ×11.2(H) mm
- Charging / power
- 3.3 VDC ±5%
- Ports / interfaces
- TTL-232
- Power Consumption
- 188 mW
- Weight
- 6 g
- Humidity
- 5% to 95% (non-condensing)
- Operating temperature
- -20°C to 60°C (-4°F to 140°F)
- Storage temperature
- -40°C to 85°C (-40°F to 185°F)
- Warranty
- 2 Years
