Emdoor · Tablet
Emdoor EM-X14M
14 inch Windows AI Rugged Laptop: Intel Core Ultra with NPU & Arc Graphics. MIL-STD-810H/IP65 14'' touchscreen.
- Operating systemWindows 11 Pro
- Display14 inch 16:9, 1920×1080, 1000 nits
- BatteryBuilt-in - 1300mah/11.1V / Built-in Polymer Lithium-ion Battery, Non-removable / 1.5 hours Hot-swappable -…
- Drop1.2m drop resistance
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Specifications
Specifications
- Dimensions
- 363.2*287.4*42.1mm
- Weight
- 2.97kg
- Color
- Black
- Display
- 14 inch 16:9, 1920×1080, 1000 nits
- Touch panel
- Optional 10-point capacitive screen,Hardness above 7H, Scratch-resistant，supports glove touch
- Cameras
- Front 5.0MP
- I/O Interface
- USB3.2 *1, USB3.0 *1，USB2.0 *1 TYPE-C, Supports Thunderbolt 4 ∮3.5mm Standard Earphone Jack *1 HDMI 2.0a mini *1 SIM card *1，TF card *1 RJ45*1 10M/100M/1000M self-adaptive， RJ45*1 10M/100M/1000Mself-adaptive(USB2.0), supports Gigabit Ethernet protocol RS232 *1, 9 fully functional lines DC19V/3.78A ∮5.5mm power interface *1 Anti-theft Lock Slot *1 Right-side Cooling Vent *1 Left-side expansion slot, optional M.2-2280 PCIe interface *1, supports SSD; Optional: M.2 E-KEY interface *1 for custom mod
- Charging / power
- AC100~240V, 19V/3.78A 71.82W output US Standard Optional: EU Standard
- Wi-Fi / WLAN
- Intel® Wi-Fi 6E (802.11 ax)
- Bluetooth
- BT5.3
- 2G/3G/4G/5G
- 4G(Optional)/5G(Optional)
- Location / GPS
- Supports single GPS or single Glonass, default GPS
- Processor
- Intel® Core™ Ultra 7 processor 155H
- GPU
- iGfx/dGfx (Intel Xe LPG Graphics)
- Operating system
- Windows 11 Pro
- RAM / storage options
- 16GB DDR5 SO-DIMM · Optional 32GB DDR5
- Storage capacity
- 256GB PCIe SSD · Optional 512GB/1TB SSD
- Battery / runtime
- Built-in - 1300mah/11.1V / Built-in Polymer Lithium-ion Battery, Non-removable / 1.5 hours Hot-swappable - 4850mah/11.55V / Removable Polymer Lithium-ion Battery, Hot-swappable / 8 hours
- NFC
- Optional
- 1D
- No
- 2D
- No
- Fingerprint
- Yes
- Operating temperature
- -20℃~60℃
- Storage temperature
- -30℃~70℃
- Humidity
- 95%, no condensation
- Protection level
- IP65 certified, MIL-STD-810H certified
- Drop specification
- 1.2m drop resistance
