Elo Touch E-Series with Android
Purpose-built for point of sale, the E-Series with Android offers a 14-inch touchscreen display, Android 14 OS, Qualcomm 6490 processor, 8GB RAM, 64GB SSD and integrated connectivity for all the perip
- Operating systemAndroid 14 with Google Play Services and EloView content deployment and management; Planned upgrade to…
- Display14.0" diagonal, Active matrix TFT LCD
- SealingTouchscreen optically bonded to LCD
Datasheet at Elo Touch Product page at Elo Touch
Runs Raptool apps in the Raptool Client, with access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Overview
Purpose-built for point of sale, the E-Series with Android offers a 14-inch touchscreen display, Android 14 OS, Qualcomm 6490 processor, 8GB RAM, 64GB SSD and integrated connectivity for all the peripherals you need. From cash drawers and printers to barcode scanners and payment devices – there is connectivity to cover it all.
- Elo Edge Connect™ allows you to seamlessly attach up to two peripherals to the edge of the touchscreen for expanded use.
- Take the E-Series beyond the counter with an optional VESA plate for wall, pole and other VESA-compatible mounting configurations.
- Built on a consistent Android platform powered by the Qualcomm 6490 chipset, Elo’s unified architecture helps businesses streamline development, deployment and scalability across POS, self-service, wayfinding, and more.
- With easy-to-use development kits, robust management tools, world class life cycle management and security, Elo can help you deliver the convenience and familiarity of Android interfaces in a secure, business-friendly way.
- Seamless Provisioning - Leverage EloView or Google Zero Touch to easily set up your device.
Best for: POS Systems for Restaurants · Retail POS Systems · Android Retail POS Systems
Specifications
Technical
- Part Number(s)
- With Stand: E579366; With Stand/CFD: E579570; With Stand/CFD and NFC: E338246
- Enclosure Color
- Black
- Touch Technology & Capacity
- PCAP (TouchPro® Projected Capacitive) - 10 Touch
- Processor
- Qualcomm Snapdragon QCS6490
- Memory (RAM)
- 8GB
- Storage
- 64GB
- OS
- Android 14 with Google Play Services and EloView content deployment and management; Planned upgrade to Android 16 and Android 18 available with OS 360 subscription
- Diagonal Size
- 14.0" diagonal, Active matrix TFT LCD
- Aspect Ratio
- 16:9
- Active Area
- 12.18" x 6.85" / 309.31 mm x 173.99 mm
- Resolution
- 1920 x 1080 @ 60Hz
- Number of Colors
- 16.2 million
- Brightness (typical)
- LCD Panel: 250 nits; TouchPro PCAP: 213 nits
- Response Time-total (typical)
- 25 ms
- Contrast Ratio
- 700:1
- Viewing Angle
- Horizontal: ±80° or 160° total / Vertical: ±80° or 160° total
- Surface Treatment
- Clear
- Peripheral Mounting
- 2x Elo Edge Connect Micro-USB 2.0; *Support for 1.2A on one port and 500mA for the remaining port
- I/O Ports
- 4x USB-A 3.0; 1x RJ45 LAN; 1x RJ12 Cash Drawer (12V/24V selectable); 1x 19V DC Input; 1x Type-C to CFD (DP alt. + USB3.0 + Power Delivery 15W -5V3A, 9V1.5A, 15V1A)
- Integrated Customer-Facing Display
- Size -10.1 inch; Resolution - 1024 x 600 @ 60 Hz; Active Display Area (H x V) - 222.72 mm x 125.28 mm; Viewing Angle - Horizontal: ±80° or 160° total / Vertical: ±80° or 160° total; Brightness - LCD Panel: 350 nits, TouchPro PCAP: 280 nits; Number of Colors - ??; Touch Technology - TouchPro PCAP; Number of Touches - 10; Sealing - Touchscreen sealed to LCD
- NFC
- Operating Frequency: 13.56 MHz; ISO 14443 Type A and B, ISO 15693 cards; Mifare, Desfire, FeliCa, NFC Forum tags; *NFC models only
- Webcam
- 8MP; Max Resolution: 3264x2448 30fps; Auto Focus
- Wireless
- 802.11a/b/g/n/ac/ax + Bluetooth 5.2
- Audio Ports
- 2x built-in Digital Microphones
- Speakers
- 2x 2W
- Power Supply
- AC input voltage: 100-240 VAC; Input frequency: 50-60 Hz
- Power Consumption (Typical)
- With CFD:; On: 14W; Off:
- Dimensions
- E-Series 14" with stand (E579366): 13.44" x 12.16" x 7.57" / 341.4 mm x 308.9 mm x 192.4 mm; E-Series 14" with stand/CFD (E579570): 13.44" x 12.16" x 7.57" / 341.4 mm x 308.9 mm x 192.4 mm; E-Series 14" with stand/CFD & NFC (E338246): 13.44" x 12.16" x 8.24" /3 41.4 mm x308.9 mm x 209.2 mm
- Shipping Box Dimensions
- E-Series 14" with stand (E579366): 18.8" x 16.5" x 13.2" / 478 mm x 418 mm x 335 mm; E-Series 14" with stand/CFD (E579570): 18.8" x 16.5" x 13.2" / 478 mm x 418 mm x 335 mm; E-Series 14" with stand/CFD & NFC (E338246): 18.8" x 16.5" x 13.2" / 478 mm x 418 mm x 335 mm
- Weight (Unpackaged)
- E-Series 14" with stand (E579366): 6.4 lbs / 2.9kg; E-Series 14" with stand/CFD (E579570): 7.9 lbs / 3.6kg; E-Series 14" with stand/CFD & NFC (E338246): 7.9 lbs / 3.6kg
- Weight (Packaged)
- E-Series 14" with stand (E579366): 14.1 lbs / 6.4kg; E-Series 14" with stand/CFD (E579570): 15.4 lbs / 7.0kg; E-Series 14" with stand/CFD & NFC (E338246): 15.4 lbs / 7.0kg
- Operating Temperature
- 0°C to 40°C / 32°F to 104°F
- Storage Temperature
- -20°C to 50°C / -4°F to 122°F
- Humidity
- Operating: 20% to 80%; Storage: 10% to 90%
- Regulatory approvals and declarations
- UL/cUL (US); FCC (US); IC (Canada); CE (Europe); CB (International); VCCI, MIC (Japan); RCM (Australia); BSMI/NCC (Taiwan); KCC (Korea); CCC/SRRC (China); United Kingdom UKCA
- Supported Countries
- US, Canada, EMEA, UK, Australia, Japan, South Korea, Mexico, Brazil, Taiwan, Argentina, India
- Real-Time Clock
- lithium coin cell battery
- Mounting Options
- VESA 75mm
- Warranty
- 2-year
- Extended Service Options
- 3 year OS 360 - Elo P/N: E897877; 4 year OS 360 - Elo P/N: E898079; 5 year OS 360 - Elo P/N: E898282; 3 year Warranty Coverage – Elo P/N: E819394; 4 year Warranty Coverage – Elo P/N: E819598; 5 year Warranty Coverage – Elo P/N: E819795; 3 year Warranty Coverage + ADP – Elo P/N: E130329; 4 year Warranty Coverage + ADP – Elo P/N: E130530; 5 year Warranty Coverage + ADP – Elo P/N: E130719; 2 year Warranty Coverage + AUR – Elo P/N: E819985; 3 year Warranty Coverage + AUR – Elo P/N: E820186; 4 year Warranty Coverage + AUR – Elo P/N: E820388; 5 year Warranty Coverage + AUR – Elo P/N: E820582; 2 year Warranty Coverage + AUR + ADP – Elo P/N: E131490; 3 year Warranty Coverage + AUR + ADP – Elo P/N: E131674; 4 year Warranty Coverage + AUR + ADP – Elo P/N: E131859; 5 year Warranty Coverage + AUR + ADP – Elo P/N: E132053
- OS Support
- Bi-monthly Android security updates available with Elo OS 360 package.
- Sealability
- Touchscreen optically bonded to LCD
- What's in the Box
- E-Series with Stand; North American Power Cable; European Power Cable; 1x Power Brick; Quick Install Guide; 2x Cable Tie
- Optional Peripherals
- Magnetic Stripe Reader (MSR) – Elo P/N: E001002; Fingerprint Scanner – Elo P/N: E134286; 2D Barcode Scanner (Black - SE2707) – Elo P/N: E393160; 2D Barcode Scanner (Black - SE4720) – Elo P/N: E384627; 2D Barcode Scanner (Black - SE4107) – Elo P/N: E245047; Status Light (Micro-USB Connectivity) - Elo P/N: E644767; Webcam - Elo P/N: E201494; RFID - Elo P/N: E673037; Speaker Bar (Black) - Elo P/N: E894719; 10-inch Wedge Customer-facing Display (With NFC) - Elo P/N: E338628; 10-inch Wedge Customer-facing Display (Without NFC) - Elo P/N: E338432
- Stands, Mounts & Kits
- 65W Replacement Cable Kit (NA & EU power cables and power brick) – Elo P/N: E514304
Data from elotouch.com product page and its specification table, checked 2026-10-27.
Lifecycle
- Sales status
- Current
- Status basis
- Listed as a current product on elotouch.com; no end-of-life notice found on the product page
