Elo Touch · POS computer

Elo Touch 15-inch (16:9) EloPOS System

The versatile EloPOS System combines modern aesthetics, modular flexibility and commercial-grade reliability. Purpose-built for point of sale, EloPOS offers a 15.6-inch touchscreen display, choice of

Operating systemNo OS; Windows 10 IoT Enterprise LTSC 64-bit; Optional - Windows 10 Professional English 64-bit
Display15.6'' diagonal, Active matrix TFT LCD (LED)
SealingTouchscreen sealed to sub-bezel; Touchscreen sealed to LCD

Datasheet at Elo Touch Product page at Elo Touch

Runs Raptool apps in the Raptool Client, with access to the scanner, camera, RFID and printers, online and offline. Scanner apps

Overview

The versatile EloPOS System combines modern aesthetics, modular flexibility and commercial-grade reliability. Purpose-built for point of sale, EloPOS offers a 15.6-inch touchscreen display, choice of Intel’s 9th generation processors and an integrated expansion hub to connect the peripherals you need - whether a customer facing display, payment reader, printer, cash drawer, barcode scanner or scale. From traditional POS to self-service applications, EloPOS delivers the durability needed to survive continuous public use and is backed by Elo’s standard 3-year warranty.

The EloPOS System is designed to offer flexibility across environments. Whether you need a fixed-lane point of sale system or a self-order solution, EloPOS can help ensure that every touch delivers the experience your employees need and your customers expect.
*Based on Passmark scores comparing 9th generation i3 and i5 vs the competitors current 6th and 7th generation processors
The expansion hub allows you to connect all of the POS peripheral support you need. From cash drawers and printers to barcode scanners and payment devices — there is connectivity to cover it all. With two models, the hub is integrated into the base of the EloPOS stand or mounted to the back of the display for pole and wall mount configurations.
EloPOS is designed with the flexibility to be mounted however you desire. With a standard VESA mounting system, and optional pole and self-service stands, EloPOS offers the modularity you need to create the solution you want. From POS terminals to self-service checkout, the EloPOS can be configured to deliver maximum impact.
The EloPOS System includes USB-C connectivity, allowing you to easily connect a 1302L customer-facing display - providing touch, data and power with just one cable. By reducing the number of cables required for setup from 3 to 1, installation and servicing is a breeze.

Best for: POS Systems for Restaurants · Retail POS Systems · Windows Retail POS Systems · Linux Retail POS Systems

Videos

Elo 15-inch (16:9) EloPOS System video

Specifications

Technical

Part Number(s): HD Models:; Celeron (J4125), No OS, 4GB RAM, 128GB SSD with I/O Hub Stand - E440439; Celeron (G4900T), No OS, 4GB RAM, 128GB SSD with I/O Hub Stand - E545668; Celeron (G4900T), Win 10, 4GB RAM, 128GB SSD with I/O Hub Stand - E546051; Celeron (J4125), Win 10, 8GB RAM, 256GB SSD with I/O Hub Stand - E397891; Celeron (G4900T), Win 10, 8GB RAM, 256GB SSD with I/O Hub Stand - E547007; Celeron (J4125), No OS, 8GB RAM, 128GB SSD, with I/O Hub Stand - E144974; Celeron (G4900T), No OS, 8GB RAM, 128GB SSD, with I/O Hub Stand - E554190; Celeron (J4125), Win 10, 8GB RAM, 128GB SSD, with I/O Hub Stand - E189048; Celeron (G4900T), Win 10, 8GB RAM, 128GB SSD, with I/O Hub Stand - E546819; Celeron (J4125), No OS, 4GB, 128GB SSD with Wall Mount I/O Hub - E441010; Celeron (G4900T), No OS, 4GB, 128GB SSD with Wall Mount I/O Hub - E546637; Celeron (J4125), Win 10, 4GB RAM, 128GB SSD with Wall Mount I/O Hub - E440808; Celeron (G4900T), Win 10, 4GB RAM, 128GB SSD with Wall Mount I/O Hub - E545479; Celeron (G4900T), No OS, 8GB RAM, 128GB SSD, with Wall Mount I/O Hub - E548715; i3, No OS, 4GB RAM, 128GB SSD with I/O Hub Stand - E441385; i3, Win 10, 4GB RAM, 128GB SSD with I/O Hub Stand - E441193; i3, No OS, 4GB RAM, 128GB SSD with Wall Mount I/O Hub - E441781; i3, Win 10, 4GB RAM, 128GB SSD with Wall Mount I/O Hub - E441575; i3, Win 10, 8GB RAM, 128GB SSD with I/O Hub Stand - E262258; i3, Win 10, 8GB RAM, 256GB SSD with I/O Hub Stand -E397698; i3, No OS, 8GB RAM, 128GB SSD with Wall Mount I/O Hub - E263402; i5, No OS, 8GB RAM, 128GB SSD with I/O Hub Stand - E442161; i5, Win 10, 8GB RAM, 128GB SSD with I/O Hub Stand - E441968; i5, No OS, 8GB RAM, 128GB SSD with Wall Mount I/O Hub - E442550; i5, Win 10, 8GB RAM, 128GB SSD with Wall Mount I/O Hub - E442365; i5, Win 10, 8GB RAM, 256GB SSD with Wall Mount I/O Hub - E892954; i5, Win 10, 8GB RAM, 512GB SSD with Wall Mount I/O Hub -E841559; i5, Win 10, 16GB RAM, 128GB SSD with I/O Hub Stand - E877703; i5, Win 10, 8GB RAM, 256GB SSD with I/O Hub Stand - E892761; Full HD Models:; Celeron (G4900T), No OS, 4GB RAM, 128GB SSD with I/O Hub Stand - E545297; Celeron (J4125), Win 10, 4GB RAM, 128GB SSD with I/O Hub Stand - E935367; Celeron (G4900T), Win 10, 4GB RAM, 128GB SSD with I/O Hub Stand - E546242; Celeron (G4900T), No OS, 4GB RAM, 128GB SSD with Wall Mount I/O Hub - E547750; Celeron (G4900T), Win 10, 4GB RAM, 128GB SSD with Wall Mount I/O Hub - E548331; Celeron (G4900T), No OS, 8GB RAM, 128GB SSD with I/O Hub Stand - E547381; Celeron (G4900T), Win 10, 8GB RAM, 128GB SSD with I/O Hub Stand - E548147; i3, Win 10, 8GB RAM, 128GB SSD, with I/O Hub Stand - E317130; i3, Win 10, 8GB RAM, 512GB SSD, with I/O Hub Stand - E664384; i3, No OS, 8GB RAM, 256GB SSD, with Wall Mount I/O Hub - E899520; i3, No OS, 4GB RAM, 128GB SSD with I/O Hub Stand - E935967; i3, Win 10, 4GB RAM, 128GB SSD with I/O Hub Stand - E935775; i3, No OS, 4GB RAM, 128GB SSD with Wall Mount I/O Hub - E407627; i3, No OS, 8GB RAM, 128GB SSD with Wall Mount I/O Hub -E880567; i3, Win 10, 4GB RAM, 128GB SSD with Wall Mount I/O Hub - E396134; i3, Win 10, 8GB RAM, 128GB SSD with Wall Mount I/O Hub - E727037; i5, No OS, 8GB RAM, 128GB SSD with I/O Hub Stand - E936365; i5, Win 10, 8GB RAM, 128GB SSD with I/O Hub Stand - E936163; i5, No OS, 8GB RAM, 128GB SSD with Wall Mount I/O Hub - E936750; i5, Win 10, 8GB RAM, 128GB SSD with Wall Mount I/O Hub - E936556; i5, Win 10, 8GB RAM, 256GB SSD with I/O Hub Stand - E536624; i5, Win 10, 16GB RAM, 256GB SSD with I/O Hub Stand - E939305; i5, Win 10, 16GB RAM, 256GB SSD with Wall Mount I/O Hub - E939498; i5, Win 10, 32GB RAM, 1TB SSD with I/O Hub Stand - E580923
Enclosure Color: Black
Touch Technology & Capacity: PCAP (TouchPro® Projected Capacitive) - 10 Touch
Processor: Celeron: Intel Celeron Processor J4125 (4M Cache, up to 2.7 GHz) or Intel Celeron G4900T Processor (2M Cache, up to 2.9 GHz); i3: Intel Core i3-9100TE Processor (6M Smart Cache, up to 3.20 GHz by Intel Turbo Boost Technology 2.0); i5: Intel Core i5-9500TE Processor (9M Smart Cache, up to 3.60 GHz by Intel Turbo Boost Technology 2.0) with Intel vPro™ Support
Chipset: Celeron Models: N/A or Intel H310 Express; i3 Models: Intel H310 Express; i5 Models: Intel Q370 Express
Graphics: Celeron Models: Intel UHD Graphics 600 or Intel UHD Graphics 610; i3 & i5 Models: Intel UHD Graphics 630
BIOS: AMI
Memory (RAM): Celeron Models: 4GB 2666MHz DDR4 SO-DIMM on 1 of 2 slots (expandable to 8GB); i3 Models: 4GB 2666MHz DDR4 SO-DIMM on 1 of 2 slots (expandable to 32GB); i5 Models: 8GB 2666MHz DDR4 SO-DIMM on 1 of 2 slots (expandable to 32GB); Note: Check brand of the memory included in your unit before purchasing the memory kit.
Storage: 128GB M.2 SATA SSD, 80 TBW; 256GB M.2 SATA SSD, 160 TBW; Optional M.2 PCIe (NVMe) SSD for select SKUs; GB equals one billion bytes when referring to storage capacity. Accessible capacity may be less.
TPM: 2.0
Active Management Technology (AMT): Celeron Models: N/A; i3 Models: N/A; i5 Models: Active Management Technology (Intel AMT 11.0) Support.
Diagonal Size: 15.6'' diagonal, Active matrix TFT LCD (LED)
Aspect Ratio: 16:9
Active Area: 13.55" x 7.62" / 344.2 mm x 193.5 mm
Resolution: HD Models:; 1366 x 768 @ 60Hz; Full HD Models:; 1920 x 1080 @ 60Hz
Number of Colors: 262,000
Brightness (typical): HD Models:; LCD Panel: 220 nits; PCAP: 187 nits; Full HD Models:; LCD Panel: 300 nits; PCAP: 255 nits
Response Time-total (typical): HD Models:; 10 msec; Full HD Models:; 25 msec
Contrast Ratio: FHD Models: 700:1 / HD Models: 400:1
Viewing Angle: HD Models: Horizontal: 45°/45° or 90° total / Vertical: 15°/35° or 50° total; Full HD Models: Horizontal: 80°/80° or 160° total / Vertical: 80°/80° or 160° total
USB Ports: 3 x USB 3.0 (1 on display head, 2 on I/O); 2 x USB 2.0 (on I/O); 4 x Micro USB 2.0 (on display head)
Powered USB: 1 x 24V on I/O; 2 x 12V on I/O
Ethernet Port: 1 x LAN RJ45 (Gigabit)
Serial Ports: 2 x RJ45
Cash Drawer Port: 12V/24V Cash Drawer Port on I/O (EPSON Pinout, 24V default; selectable by internal switch)
Wireless: Wi-Fi 802.11 a/b/g/n/ac 2.4GHz and 5GHz
Bluetooth: Bluetooth 5.0
Additional Video Out: 1 x Full-function USB-C (Power up to 27W, USB 3.0, Display Port)
Audio Ports: 1 x 3.5 mm headset jack
Speakers: 2 x 2W internal speakers
OS: No OS; Windows 10 IoT Enterprise LTSC 64-bit; Optional - Windows 10 Professional English 64-bit
Languages: Windows 10 - 36 Language groups
Power Supply: External 24VDC universal-type power supply brick; AC input voltage: 100-240 VAC; Input frequency: 50-60 Hz; Maximum output power: 180W
Power Consumption (Typical): HD Models:; Celeron: 24W; i3: 65W; i5: 74W; Full HD Models:; Celeron: 26W; i3: 67W; i5: 76W
Dimensions: With Stand: 15.2" x 14.54" x 8.71" / 386.2 mm x 369.3 mm x 221.2 mm; Without Stand: 15.2" x 9.8" x 2.89" / 386.2 mm x 248.9 mm x 73.3 mm
Shipping Box Dimensions: With Stand: 18.19" x 11.77" x 18.5" / 462 mm x 299 mm x 470 mm; Without Stand: 18.19" x 8.5" x 13.57" / 462 mm x 216 mm x 346 mm
Weight (Unpackaged): With Stand: 10.8 lbs / 4.9 kg; Without Stand: 6.4 lbs / 2.9 kg
Weight (Packaged): With Stand: 16.1 lbs / 7.3 kg; Without Stand: 10.8 lbs / 4.9 kg
Operating Temperature: 0°C to 35°C / 32°F to 95°F
Storage Temperature: -20°C to 60°C / -4°F to 140°F
Humidity: Operating: 20% to 80%; Storage: 5% to 95% (38.7℃ max wet bulb temperature)
Energy Star: Energy Star 7.1
Regulatory approvals and declarations: United States UL, FCC; Canada cUL; Germany TUV; Europe CE; International CB; United Kingdom UKCA; Mexico NOM; Australia RCM; New Zealand R-NZ; Japan VCCI; Argentina S-Mark; China CCC; Korea KCC for i3 and i5 FHD models / i5 HD models; Taiwan BSMI for i3 and i5 FHD models; Singapore IMDA for i3 FHD models / i5 HD models; Malaysia SIRIM for i3 FHD models / i5 HD models; Thailand NBTC for i3 FHD models / i5 HD models
Real-Time Clock: CR2032 lithium metal battery
MTBF: 50,000 hours demonstrated
Mounting Options: 75mm VESA mount
Warranty: 3-year
Extended Service Options: 4 year warranty coverage - Elo P/N: E819598; 5 year warranty coverage - Elo P/N: E819795; 3 year warranty coverage + AUR - Elo P/N: E820186; 4 year warranty coverage + AUR - Elo P/N: E820388; 5 year warranty coverage + AUR - Elo P/N: E820582
Sealability: Touchscreen sealed to sub-bezel; Touchscreen sealed to LCD
Power Cables: North American and European power cables included
Other Features: Serviceable internal components.; Models with a stand for desktop application.; Models without a stand for 75mm VESA mounting.; Kensington lock.
What's in the Box: EloPOS System; North America Power Cord; EU Power Cord; Power Adapter – 180W; Cable RJ-45 to DB-9; Cable cover locking screw; Quick Installation Guide (QIG)
Upgrade Options: 4GB 2666 MHz DDR4 Memory SO-DIMM - Elo P/N: E264186; 8GB 2666 MHz DDR4 Memory SO-DIMM - Elo P/N: E264375; 16GB 2666 MHz DDR4 Memory SO-DIMM - Elo P/N: E263989; M.2 SATA 128GB SSD – Elo P/N: E206352; M.2 SATA 256GB SSD – Elo P/N: E206556; Note: Celeron SKUs only support 4GB DDR4 per slot
Optional Peripherals: Magnetic Stripe Reader (MSR) – Elo P/N: E001002; Fingerprint Scanner – Elo P/N: E134286; 10" LCD Customer-facing Display (10 touch) – Elo P/N: E155834 (requires both the display mount kit E835969 and Elo 2ft USB-C cable E969524)); 10" LCD Customer-facing Display (no touch) – Elo P/N: E324341 (requires both the display mount kit E835969 and Elo 2ft USB-C cable E969524)); 1302L Customer-facing Display (10 touch) – Elo P/N: E683595 (requires both the display mount kit E835969 and Elo 2ft USB-C cable E969524)); 2D Barcode Scanner (Black - SE4720) – Elo P/N: E384627; EMV Cradle for MagTek eDynamo - Elo P/N: E375343; EMV Cradle for Ingenico RP457c (with Audio Jack, BT and USB) - Elo P/N: E586981; EMV Cradle for Ingenico RP457c (with BT and USB) - Elo P/N: E710930; Status Light (Micro-USB Connectivity) - Elo P/N: E644767; RFID - Elo P/N: E673037; Speaker Bar (Black) - Elo P/N: E894719; Speaker Bar (White) - Elo P/N: E133780
Stands, Mounts & Kits: Shelf Mount Bracket (75mm or 100mm VESA) - Elo P/N: E043382; Floor Stand (75mm or 100mm VESA) - Elo P/N: E048069; Pole Mount – 6 inch (75mm or 100mm VESA) - Elo P/N: E047458; Pole Mount – 12 inch (75mm or 100mm VESA) - Elo P/N: E047663; Pole Mount – 18 inch (75mm or 100mm VESA) - Elo P/N: E047864; Pole Mount Bracket (75mm or 100mm VESA) - Elo P/N: E045151; Rear-facing Display Mount - Elo P/N: E835969 (Requires authorized 2ft USB-C cable); Power Brick Kit, 24V 180W - Elo P/N: E845269; Elo 2ft authorized USB-C cable - Elo P/N: E969524; RJ45 to DB9 cable kit - Elo P/N: E641484

Data from elotouch.com product page and its specification table, checked 2026-10-27.

Lifecycle

Sales status: Current
Status basis: Listed as a current product on elotouch.com; no end-of-life notice found on the product page
