Citizen · Receipt printer
Citizen CT-S801III
With a print speed of 500mm/sec, the CT-S801III originally set the standard for high speed POS printing and is still among the fastest machines in its class. Offering a top paper exit for retail applications, the CT-S801III has an advanced, two-color backlit LCD, ensuring quick setup and total control of all print functions.
- Operating systemDevelopment kits for Windows Mobile, Android, Blackberry, Symbian, etc. OPOS JavaPOS ESC/POS® emulation…
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Specifications
Specifications
- Printing Technology
- Direct Thermal
- Resolution
- 203 dpi
- Print Speed (maximum)
- 500mm/sec
- Print Width (maximum)
- 80 mm
- Media type
- Thermal receipt paper
- Media Width (min to max)
- 58 / 60 / 80 / 82.5 mm
- Media Thickness (min to max)
- 65 to 75 μm or 75 to 85 μm
- Roll Size (max), Core Size
- 83 mm outside diameter
- Paper
- Mitsubishi Paper Mills P220AG normal type 65 Mitsubishi Paper Mills P220A Mitsubishi Paper MillsHP220AB-1 highly conserved type 75 Mitsubishi Paper Mills F230AA normal type 65 Mitsubishi Paper Mills P220AB normal type 85 Mitsubishi Paper Mills PB670 (2 color paper) Oji Paper PD150R normal type 75 Oji Paper PD160R high storage type 65/75 Nippon Paper TF50KS-E-2D
- Number of columns
- On 58mm paper up to 35 digits (12 x 24 font A) On 58mm paper up to 46 digits (9 x 17 font B) On 58mm paper up to 52 digits (8 x 16 font C) On 80mm paper up to 48 digits (12 x 24 font A) On 80mm paper up to 64 digits (9 x 17 font B) On 80mm paper up to 72 digits (8 x 16 font C) On 82.5mm paper up to 53 digits (12 x 24 font A) On 82.5mm paper up to 71 digits (9 x 17 font B) On 82.5mm paper up to 80 digits (8 x 16 font C)
- Character table / Code page
- Alphanumeric International characters Katakana Thai code18 WPC1252 437 850 852 857 858 860 863 864 865 866
- Line spacing
- 4.23mm (1/6 inch); adjustable by user comand
- Main Interface
- USB 2.0 full speed
- Optional interfaces
- Serial (RS-232C compliant) Ethernet + USB host Powered USB Ethernet Bluetooth with Apple™ MFi compatibility Parallel (IEEE 1284 compliant) USB with hub
- Input buffer
- 4K bytes / 45 bytes
- Drivers and software
- Free-of-charge from website, including support for various platforms
- Emulations (Languages)
- ESC/POS™
- Barcodes
- UPC-A UPC-E EAN-13 (JAN-13) EAN-8(JAN-8), CODE39 CODE93 CODE128 CODABAR(NW-7) PDF 417 QR Code
- Size (W x D x H) and Weight
- 145x192x148 mm, 2 Kg, DC version 145x192x120, 1.6 Kg
- Warranty
- 3 years
- Cutter
- Guillotine type, full and partial
- Drawer kick-out
- 2 Drawers
- Charging / power
- 110 - 240 V, 50/60 Hz
- Reliability
- 200 Million pulses or 150 Km, 2 million cuts
- Operation environment
- +5 to +45°C, 10% - 90% RH, non condensing
- Storage environment
- -20 to +60°C (10% to 90% RH non condensing)
- EMC and safety standards
- CE TUV UL C-UL FCC class A VCCI
- Accessories And Options
- Cutter (full / partial)
- Naturally Citizen Green Concept
- ENERGY STAR® compliant Small footprint Recyclable packacking Print, Sleep and Standby modes
- Easy maintenance
- Tool-free maintenance
- Operating system
- Development kits for Windows Mobile, Android, Blackberry, Symbian, etc. OPOS JavaPOS ESC/POS® emulation Windows 7 & 10 Linux CUPS iOS Android Windows 11 Windows Server 2022
- Applications
- Applications: Hospitality Kiosk Kitchen Retail
