Chainway P100 AI 5G Industrial Tablet
The Chainway P100 is a cutting-edge 5G industrial tablet featuring a 10.95" high-brightness HD display and an optional 2.6GHz octa-core CPU for enhanced user experience and extended product lifecycle.
- Operating systemAndroid 14
- Display10.95”, IPS, 1920x1200
- ScanningZebra: SE4100, SE55; CM60
- SealingIP67 per lEC sealing specifications; IP68/IP69K available upon request
- DropMIL-STD-810H (SGS Test): Multiple 1.2 m/3.94 ft. drops to concrete across the operating temperature range
Runs Raptool WMS and other Raptool apps in the Raptool Client, with full access to the scanner, camera, RFID and printers, online and offline. Scanner apps
Videos
Specifications
Platform
- Operating system
- Android 14
- Processor
- Octa-core, 2.4GHz Octa-core, 2.6GHz (Optional)
- RAM / storage options
- 4GB+64GB / 8GB+256GB (Optional)
Display
- Display size
- 10.95”, IPS, 1920x1200
- Touch panel
- Corning Glass, multi-touch panel, gloves and wet hands supported
- Keyboard / keys
- 1 scan key, 1 power key, 2 volume keys (+/-), 2 virtual keys
Data capture
- Scan engines / capture options
- Zebra: SE4100, SE55; CM60
- Barcode formats
- UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5,
- Cameras
- 5 MP 13MP Autofocus with flash; optional 16MP
Power
- Charging / power
- 10000mAh removable main battery with meter; Support fast charge 0.5W
Connectivity
- Wi-Fi / WLAN
- Support 802.11 a / b / g / n / ac / ax, 2.4G / 5G dual-band 2*2 MIMO antennas
- Bluetooth
- Bluetooth V5.2, support Bluetooth headset
- Location / GPS
- GPS/AGPS,GLONASS, BeiDou, Galileo, Dual-frequency positioning (L1 + L5)
- Ports / interfaces
- USB 3.0 Type-C, OTG, Support USB Type-C Digital Earphone
Rugged
- IP / sealing
- IP67 per lEC sealing specifications; IP68/IP69K available upon request
- Drop specification
- MIL-STD-810H (SGS Test): Multiple 1.2 m/3.94 ft. drops to concrete across the operating temperature range
- Operating temperature
- -20 °C to 50 °C / 4 °F to 122 °F
- Storage temperature
- -40 °C to 70 °C / -40 °F to 158 °F
- Humidity
- 5% RH - 95% RH (non condensing)
Size
- Weight
- 802g / 28.29oz. (for standard version)
- Dimensions
- 263.5 x 175.0 x 13.5mm / 10.37 x 6.89 x 0.53in. (for standard version)
