Elo Touch Elo Backpack for Linux
Enterprise Linux in a box. Scale your deployments.
- Operating systemLinux Debian 10
Overview
The Elo Backpack is a powerful, commercial-grade Linux PC designed to simplify scaling Elo’s enterprise Linux platform across sizes and form factors. Simply pair the Elo Backpack Linux device with any Elo touchscreen from 7-65 inches to create a consistent deployment that is cost effective and optimized for commercial use.
- With decades of development and customizations made to support global enterprise customers, Elo’s Linux-based platform offers Linux device drivers, uniform SDKs, a constantly growing set of tools and an expansive lineup across sizes and form factors.
- From digital signage and self-service kiosks to point of sale, kitchen display systems (KDS) and automation controls, the Elo Backpack Linux PC offers the connectivity, performance and durability to power almost any application.
- Purpose-built to accommodate compact spaces, the Elo Backpack Linux device offers a small footprint in both size and weight.
- Easily secure the Elo Backpack Linux PC to any counter or in a kiosk with the built-in 75mm or 100mm VESA mount.
- Equipped with Rockchip 6-core processor and your choice of Debian 10 distributions or newer, the Elo Backpack Linux PC delivers the performance your business needs.
Best for: Kitchen Display Systems · Computers for Kitchen Display Systems · Conference Room Technology · Conference Room Accessories
Specifications
Technical
- Part Number(s)
- E143585
- Enclosure Color
- Black
- Processor
- Rockchip RK3399
- Memory (RAM)
- 4GB LPDDR4
- Storage
- 32GB
- Wireless
- 802.11a/b/g/n/ac + Bluetooth 5.0; Via external antenna
- I/O Ports
- HDMI; 4x USB 3.0 support; USB-C output; Micro SD slot; GPIO; Ethernet 1x LAN (Gigabit); DC in
- OS
- Linux Debian 10
- Resolution
- USB-C: 3840 x 2160 @60fps; HDMI: 3840 x 2160 @60fps
- Power Supply
- AC input voltage: 100-240 VAC; Input frequency: 50-60 Hz; power adapter (included in accessory box)
- Power Consumption (Typical)
- On: 3.7W; Off: 0.28W; Sleep: 3.18W
- Mounting Options
- VESA 75mm and 100mm
- Dimensions
- 4.5" x 5.5" x 1.0" / 114 mm x 139 mm x 25.4 mm
- Shipping Box Dimensions
- Individual System: 14.6" x 8.2" x 2.4" / 371 mm x 208 mm x 62 mm; 8 systems/carton: 17.4" x 10.6" x 16.3" / 441 mm x 270 mm x 413 mm
- Weight (Unpackaged)
- 0.82 lbs / 0.37 kg
- Weight (Packaged)
- Individual System: 0.82 lbs / 0.37 kg; 8 systems/carton: 22.38 lbs / 10.15 kg
- Operating Temperature
- 0°C to 40°C / 32°F to 104°F
- Storage Temperature
- -20°C to 50°C / -4°F to 122°F
- Humidity
- Operating: 20% to 80%; Storage: 10% to 95%
- Real-Time Clock
- lithium coin cell battery
- MTBF
- 50,000 hours demonstrated
- Regulatory approvals and declarations
- UL/cUL (US); FCC (US); IC (Canada); CE (Europe); CB (International); VCCI, MIC (Japan); RCM (Australia)
- Warranty
- 2-year
- Extended Service Options
- 3 year warranty coverage - Elo P/N: E895914; 4 year warranty coverage - Elo P/N: E896120; 5 year warranty coverage - Elo P/N: E896322; 2 year warranty coverage + AUR - Elo P/N: E896513; 3 year warranty coverage + AUR - Elo P/N: E896699; 4 year warranty coverage + AUR - Elo P/N: E896903; 5 year warranty coverage + AUR - Elo P/N: E897104
- What's in the Box
- Backpack 4; North American Power Cable; European Power Cable; 1x Power Brick with locking screw; 2x Antenna; Quick Install Guide
- Optional Accessories
- Replacement power brick kit - Elo P/N: E682057
Data from elotouch.com product page and its specification table, checked 2026-10-27.
Lifecycle
- Sales status
- Current
- Status basis
- Listed as a current product on elotouch.com; no end-of-life notice found on the product page
