Overview

The Elo AI Edge Pack delivers enterprise-grade edge computing powered by an Intel ™ Core ™ i9 processor with integrated Intel ™ Iris ™ graphics and choice of NVIDIA ™ RTX 5080 GPU or Hailo NPU acceleration, supporting up to 1800 TOPS of AI performance. By processing data locally, the Elo AI Edge Pack minimizes latency, strengthens security, and reduces cloud dependence—enabling real-time control for automation, AI computing, and data-heavy applications. With support for up to 192GB DDR5 RAM, dual M.2 NVMe drives (RAID-capable), and up to 4TB of storage, the Elo AI Edge Pack provides the scalable edge computing, memory, and graphics performance needed to power current operations and prepare for next-generation innovation.

By processing data at the edge, the Elo AI Edge Pack reduces the delays associated with cloud round-trips. This makes it ideal for automation, autonomous systems, and applications that require immediate responses. Aggregating and processing data locally also reduces bandwidth usage while ensuring critical information is acted on instantly.
The Elo AI Edge Pack puts you back in control of your infrastructure. By processing workloads locally, it minimizes latency, strengthens data privacy, and supports compliance—while reducing the costs of cloud transfers and storage. Built for cloud repatriation, it runs complex workloads at the edge and sends only essential data off-site, improving resiliency and ensuring your most critical information stays protected.
Purpose-built for environments where space is limited, the Elo AI Edge Pack offers powerful computing closer to where your data is created. Whether placed on a shelf or mounted on a rack, it's designed to fit seamlessly into diverse edge installations.
Designed to keep your systems connected and secure, the Elo AI Edge Pack offers four LAN ports for redundancy and improved throughput—ensuring reliable, hardwired performance across your network. With flexible I/O options, it easily connects to the peripherals and devices your business depends on, from POS systems and sensors to cameras and industrial controllers.
From advance unit replacement to extended warranties, EloCare delivers service and support from the people who know your Elo products best.

Specifications

Technical

Part Number(s): NVIDIA GeForce RTX 5080, North America - E540147; Hailo 0808S, North America - E704846; NVIDIA GeForce RTX 5080, EMEA - E682675; Hailo 0808S, EMEA - E745349
Processor: Intel Processor i9 14900 (36M Smart Cache, up to 5.80 GHz)
Chipset: Intel680E
Graphics: Intel Graphics
BIOS: AMI
Trusted Platform Module (TPM): TPM 2.0
Memory (RAM): 96GB 5600MHz DDR5 U-DIMM on 3 slots; (Expandable to 192GB maximum1 on 4 slots, Varies by model)
Storage: 1TB M.2 PCIe (NVMe) SSD; (2 slots, Varies by model)
PCIEx16 Addin Card: NVIDIA GeForce RTX 5080 SOLID CORE OC 16GB; Hailo 0808S; Varies by model
OS: No OS
I/O Ports: 4x RJ45 LAN (2.5 Gigabit) Port; 8x USB 3.0 Ports; 2x Display Ports; 1x HDMI; 1x VGA; 3 x Audio Port (3.5 mm Line in/Out /Mic In); *NVIDIA GeForce RTX 5080 configuration includes an add-in I/O card providing additional 3× DisplayPort and 1× HDMI outputs.
Control Buttons: Power Button
Power Status LED: Off: no Light, On: Green, Sleep: flash Green
Power Supply: AC input voltage: 100-240 VAC 850W; Input frequency: 50-60 Hz; Maximum output power: 66W(3.3V)*, 100W(5V)*, 849.6W(12V)**; * Maximum continuous total DC output power should not exceed 850 W.; ** Maximum continuous combined load on +3.3 VDC and +5 VDC outputs shall not exceed 100 W.
Power Consumption (Typical): Without Peripherals; On E540147: 660W; On E704846: 280W; Sleep: 3.4W; Off: 0.7W
Other Features: Serviceable internal components
Power Cables: North American or European power cables (Varies by model)
Dimensions: 13.54" x 14" x 6.86" / 344 mm x 356.7 mm x 174.2 mm
Shipping Box Dimensions: 18.5" x 18.5" x 14.5" / 470 mm x 470 mm x 370 mm
Weight (Unpackaged): NVIDIA GeForce RTX 5080: 19.4 lbs / 8.9 kg; Hailo 0808S: 17.6 lbs / 8 kg
Weight (Packaged): NVIDIA GeForce RTX 5080: 28.6 lbs / 13 kg; Hailo 0808S: 22 lbs / 10.3 kg
Operating Temperature: Operating: 0°C to 35°C (32°F to 95°F)*; Storage: -20°C to 60°C (-4°F to 140°F); *The thermal report pass airflow 0.5m/s + CPU Minimum assured power condition.
Storage Temperature: Operating: 20% to 80%; Storage: 5% to 95% (38.7℃ max wet bulb temperature)
Real-Time Clock: CR2032 lithium metal battery
Regulatory approvals and declarations: Canada cUL, IC; United States UL, FCC; RoHS CoC; Japan VCC; International CB
Warranty: 3-year
Extended Service Options: 4 year warranty coverage - Elo P/N: E819598; 5 year warranty coverage - Elo P/N: E819795; 3 year warranty coverage + AUR - Elo P/N: E820186; 4 year warranty coverage + AUR - Elo P/N: E820388; 5 year warranty coverage + AUR - Elo P/N: E820582
What's in the Box: Elo AI Edge Pack; North America Power Cord / EU Power Cord (Varies by model); Quick Installation Guide (QIG); Cable tie

Data from elotouch.com product page and its specification table, checked 2026-10-27.

Lifecycle

Sales status: Current
Status basis: Listed as a current product on elotouch.com; no end-of-life notice found on the product page
