Specifications

Technical

Part Number(s): E392443
Enclosure Color: Black
Compatibility: M50 Mobile Computer (requires DC11 holder sold separately.); M60 Mobile Computer; DC11 holder for M50/M50C - E688468; DC11 holder for M50/M50C with rubber boot - E688653
I/O Ports: 12V DC IN Jack Connector
Dimensions: Countertop: 2.79" x 19.82" x 3.93" / 70.9 mm x 495.5 mm x 99.8 mm; Wall mount: 4.87" x 19.82" x 3.99" / 123.7 mm x 495.5 mm x 101.3 mm
Shipping Box Dimensions: 21.81" x 5.75" x 6.73" / 554 mm x 146 mm x 171 mm
Mounting Options: Countertop or Wall (with included wall mount bracket)
Weight (Unpackaged): 2.9 lbs / 1.35 kg
Weight (Packaged): 7.17lbs / 3.25 kg
Operating Temperature: 0°C to 40°C / 32°F to 104°F
Storage Temperature: -20°C to 50°C / -4°F to 122°F
Humidity: Operating: 20% - 80%; Storage: 10% - 95%
Regulatory approvals and declarations: UL, FCC (US) - Class B; cUL, IC (Canada); CB (International safety); CE (Europe) - Class B; VCCI (Japan); RCM (Australia); China RoHS
MTBF: 50,000 hours demonstrated
Warranty: 1-year
What's in the Box: DC11 4 slot device charger (Holders for M60 without rubber boot are pre-installed); 4x holders for M60/M60C/M60S/M60SC with rubber boot; Power Adapter 12V/7.5A - 90W; US power cord; EU power cord; Wall mount bracket; 1x Tie wrap for cable management; 4x screws for wall/desk mounting; QIG
Optional Accessories: DC11 holder for M50/M50C - E688468; DC11 holder for M50/M50C with rubber boot - E688653

Data from elotouch.com product page and its specification table, checked 2026-10-27.

Lifecycle

Sales status: Current
Status basis: Listed as a current product on elotouch.com; no end-of-life notice found on the product page
