Elo Touch COACh AT Controller Chip
The COACh™ V (Controller On A Chip, 5th generation) is a compact universal resistive touchscreen controller chip solution. It supports both serial and USB communication interfaces and is capable of in
Overview
The COACh™ V (Controller On A Chip, 5th generation) is a compact universal resistive touchscreen controller chip solution. It supports both serial and USB communication interfaces and is capable of interfacing to AccuTouch™ five-wire resistive touchscreens.
- The COACh V works through an RS232-style serial interface or via USB with auto-detection. If configured for USB operation the COACh V is classified as self powered.
- Regardless of the configuration, operation is automatically detected on power up and needs no user intervention. The COACh V fully supports the Elo SmartSet protocol and all program drivers, both serial and USB.
- On-board calibration, coordinate scaling, and programmable output rates allow for application-specific performance tuning
Specifications
Technical
- Part Number(s)
- E196429
- Technology
- 5-Wire Resistive (AccuTouch®)
- Number of Touches
- Single Touch
- Input Methods
- Finger; Gloved hand; Passive stylus
- Dimensions
- 7 mm x 7 mm x 1.6 mm
- Surface Treatment
- Clear
- Input Voltage
- 5V +/- 10%
- Report Rate
- 10ms
- Baud Rate
- For RS232: 9600 (default) and 19200
- Operating Temperature
- -40°C to 85°C
- Storage Temperature
- -65°C to 125°C
- Humidity
- 10% o 90% RH, noncondensing
- Warranty
- 2-year
- Controller Cables
- Serial cable: P/N D16890-000; USB cable: P/N D38640-000; Dual serial/USB cable: P/N D40022-000
Data from elotouch.com product page and its specification table, checked 2026-10-27.
Lifecycle
- Sales status
- Current
- Status basis
- Listed as a current product on elotouch.com; no end-of-life notice found on the product page
